Aiphone IXW-MA
- New features available for North America with a firmware update
- Program using the IX Series Support tool
- Powered over POE, no additional power supply required!
- 4 activation inputs, 10 relay outputs
- Line Supervision events from IX Series master can trigger a relay closure
- Activate with either relay output from IX series stations
Power Source
802.3af PoE compliant
Power Draw
Standby: 43 mA; Maximum: 135 mA
Relay Output
Relays 1-4: Form C 24V AC/DC 500mA
Relays 5-10: Form A 24V AC/DC 500mA
LAN
Ethernet (10BASE-T, 100BASE-TX)
Protocols
IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
Encryption system
TLS1.0, TLS1.1, TLS1.2
Port Security
IEEE 802.1X
Operating Temp
14° ~ 104°F (-10° ~ 50°C)
Dimensions
7-1/2″ x 9-5/8″ x 13/16″
Weight
1.39 lbs
