描述
ASUS RT-BE86U
RT-BE86U WiFi 7
Features
- 6800 Mbps ultra-fast dual-band network speed
- Equipped with a monster-level total network capacity of 20G
- 10G WAN/LAN port
- Four 2.5G LAN ports
- ASUSWRT 5.0 Interface
Specifications
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 7 (802.11be) IPv4 IPv6 |
| Product Segment | BE6800 ultimate BE performance : 1032+5764 Mbps |
| WiFi Data Rate | WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps WiFi 7 (802.11be) (5GHz): up to 5764 Mbps |
| Antenna | External antenna x 3； Internal antenna x 1 |
| Transmit / Receive | 2.4GHz 3×3 5GHz 4×4 |
| Processor | 2.6GHz quad-core processor |
| Memory | 256 MB Flash and 1 GB RAM |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160 MHz bandwidth |
| Operating Frequency | 2.4 GHz 5 GHz |
| Operating Mode | Wireless Router Mode AiMesh Node Mode Access Point Mode Media Bridge Mode Repeater Mode |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 5 A current ； 19.5 V with max. 2.31 A current |
| Product Weight (g) | 854 g |
| Product Dimensions | 235*90*316 mm |
