F-66.4B
InfraCool Basic Raised Floor Mount Fan Unit – Cool Air from Rack Top (2172 CFM @ 230V / 2104 CFM @ 208V)
F-66.4B 屬Austin Hughes伺服器機櫃及機房設備產品。傑成系統有限公司（香港防盜）為Austin Hughes產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合網絡佈線、UPS 及機房環境監測一併規劃。方案可參考Server Room 架設及維修。規格以原廠資料為準。
產品說明
F-66.4B is a basic raised floor mount fan unit with 4 EC fans that intakes air from the rack top. It maximizes aisle containment cooling performance and minimizes hot spots in server rack.
InfraCool Basic Raised Floor Mount Fan Unit F-66.4 help deliver strong cool air from the top of the rack to the underfloor via the contained aisle to high density server racks to eliminate internal hot spots. Maximizes CRAC (Computer Room Air Conditioning) efficiency and saves energy costs.
規格
| Product Series | Basic |
|---|---|
| Form Factor | Raised Floor Mount; Raised Floor Mount (Cool Air from Rack Top) |
| Fans | 4 Fans |
| Fan Capacity | 543 CFM (230V); 526 CFM (208V) |
| Max. Total Fan Capacity | 2104 CFM (208V); 2172 CFM (230V) |
| Control Method | Local |
| Cascade | None |
| Features | Automatic Fan Speed Control; Front Panel LED; Local Fan Unit ON / OFF; Local Individual Fan ON / OFF; Local Temperature Monitoring; Manual Fan Speed Control |
| MTBF | 50000 |
| Compliance | CE; FCC; REACH; RoHS3 |
