BELDEN 43907NH
Speaker Cable LSZH 8×2.5mm², CPR Eca
Product Description
Speaker Cable, 8 Conductor 2.5mm² (50 x 0.25mm) Oxygen-Free Bare Copper (High Conductivity), LSZH Insulation, LSZH Jacket, Flexible, CPR Euroclass Eca.
Technical Specifications
| Insulation | |||
| Element | Material | Nominal Diameter | Diameter +/- Tolerance |
| Conductor(s) | PE – Polyethylene | 2.85 mm | 0.1 mm |
| Central Conductor | PE – Polyethylene | 3.75 mm | 0.1 mm |
| Outer Shield | |||
| Type | Material | Coverage [%] | |
| Tape | Bi-Laminate (Alum+Poly) | 100% | |
| Outer Jacket | |||
| Material | Nominal Diameter | Diameter +/- Tolerance | |
| LSZH – Low Smoke Zero Halogen (Flame Retardant) | 12.4 mm | 0.3 mm | |
