| Pan/Tilt Range |
Pan: 0° to 355° Tilt: –15° to +90° |
| Manual Control Speed |
Pan: 0.1°/s–36°/s; Tilt: 0.1°/s–25.8°/s |
| Preset Speed |
Pan: 35.7°/s; Tilt: 27.1°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Auto Patrol |
It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
| Power-off Memory |
Yes |
| Idle Motion |
Preset; Tour |
| PTZ Locked |
Yes |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking (people) |
| Face Detection |
Supports face detection, snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first |
| Auto Tracking |
Auto tracking Lite |
| SMD |
SMD 3.0 |
| Light Warning |
Red and blue light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low |
| Sound Warning |
Offers 11 types of sound alarms, and supports importing up to 10 custom sound alarms. The sound alarm can be set to play 1 to 10 times |
| Video Compression |
H.265; H.264B; H.264M; H.264H; MJPEG(Sub Stream 1); smart H.265+; smart H.264+ |
| Streaming Capability |
3 streams |
| Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 ×480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate |
Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/VGA/CIF@ (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p @(1–25/30 fps) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 96 kbps–14848 kbps H.265: 38 kbps–8960 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| WDR |
120 dB |
| HLC |
Yes |
| White Balance |
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control |
Auto; manual |
| Noise Reduction |
2D NR; 3D NR |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Electronic (EIS) |
| Defog |
Electronic |
| Digital Zoom |
16× |
| Image Rotation |
180° |
| S/N Ratio |
≥55 dB |
| Privacy Mask |
Up to 24 areas can be set, with up to 8 areas in the same view; 8 colors available |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; MPEG2_Layer2; G.722.1 |
| Network Port |
RJ-45 (10/100 Base-T) |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; QoS; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; SMB; NFS |
| Interoperability |
ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (total bandwidth: 64 M) |
| Storage |
FTP/SFTP; Micro SD card (512 GB); NAS |
| Browser |
IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
| Management Software |
DMSS; DSS Pro; NVR |
| Mobile Client |
iOS; Android |
| Certifications |
CE: EN55032/EN55024/EN50130-4 |
| Audio Input |
1 channel (LINE IN, bare wire, built-in mic (mutually exclusive)) |
| Audio Output |
1 channel (LINE OUT, bare wire; built-in speaker (mutually exclusive)) |
| Alarm Linkage |
Capture; recording; send email; preset; alarm digital input; audio; warning light |
| Alarm Event |
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Alarm I/O |
1/1 |
| Audio I/O |
1/1 |
| Power Supply |
12 VDC, 2 A ± 10% PoE+ (802.3at) |
| Power Consumption |
Basic: 3 W Max.: 12 W (Warning light + illuminator + PTZ + speaker + heating glass) (12 VDC) Basic: 4 W Max.: 14 W (Warning light + illuminator + PTZ + speaker + heating glass) (PoE) |
| Operating Temperature |
–30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Protection |
IP66; TVS 2000 V lightning proof; surge protection; voltage transient protection |
| Product Dimensions |
142.6 mm × 151.8 mm × 236.2 mm (5.61" × 5.98" × 9.30 ") (L × W × H) |
| Net Weight |
1.58 kg (3.48 lb) |
| Gross Weight |
2 kg (4.41 lb) |
