| Pan/Tilt Range |
Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1°/s–180°/s; Tilt: 0.1°/s–90°/s |
| Preset Speed |
Pan: 0.1°/s–180°/s; Tilt: 0.1°/s–90°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Idle Motion |
Preset; Pattern; Tour; Scan |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking |
| SMD |
SMD 4.0 |
| Light Warning |
Red-Blue light warning; Flash duration: 5 s–30 s; Flash frequency: high, medium, low |
| Sound Warning |
Offers 11 sound alarm and 10 custom sound alarms can be imported. Sound can be set from 0%–100%. Play times can be set from 1-10. |
| Video Compression |
Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability |
3 streams |
| Resolution |
Overview channel: 8M (4096 × 1860); 2M (2048 × 928); 1080p (1920 × 1080); 720p (1280 × 720); 1024 × 448; D1 (704 × 576/704 × 480);VGA (640 × 480);CIF (352 × 288/352 × 240); Detail channel: 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480);VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate |
Overview channel: Main stream: 4096 × 1860 @(1–25/30 fps) Sub stream 1: 1024 × 448/D1/VGA/CIF @(1–25/30 fps) Sub stream 2: 2048 × 928/1080p/1.3M/720p @(1–25/30 fps); Detail channel: Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/VGA/CIF @(1–25/30 fps) Sub stream 2: 1080p/1.3M/720p/ @(1–25/30 fps) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
Overview channel: H264: 128 kbps–16,384 kbps H265: 51 kbps–13,312 kbps; Detail channel: H264: 96 kbps–16,384 kbps H265: 38 kbps–10,240 kbps |
| Day/Night |
Overview channel: Auto; Color; B/W; Electronic Detail channel: Auto; Color; B/W; Electronic |
| BLC |
Yes |
| WDR |
Overview channel: DWDR; Detail channel: 120 dB |
| HLC |
Yes |
| White Balance |
Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control |
Overview channel: Auto; manual; gain prio Detail channel: Auto; manual; gain prio |
| Noise Reduction |
Overview channel: 2D NR; 3D NR Detail channel: Auto: 2D NR; 3D NR |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Overview channel: NA Detail channel: Electronic Image Stabilization (EIS) |
| Defog |
Overview channel: Electronic Detail channel: Electronic |
| Digital Zoom |
Overview channel: NA; Detail channel: 16× |
| Image Rotation |
Overview channel: NA Detail channel: 180 |
| S/N Ratio |
Overview channel: ≥55 dB Detail channel: ≥55 dB |
| Audio Compression |
PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729 |
| Network Port |
RJ-45 (100/1,000 Base-T) |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; QoS; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; NFS |
| Interoperability |
ONVIF (Profile S & Profile G & Profile T);CGI;SDK;P2P |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (total bandwidth: 64 M) |
| Storage |
Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser |
web5.0: IE 9 and later versions; Chrome 41 and later versions; Firefox 52 and later versions; Safari 10 and later versions |
| Management Software |
DMSS; DSS Pro |
| Mobile Client |
iOS; Android |
| Management Software |
DMSS; DSS Pro |
| Mobile Client |
iOS; Android |
| Certifications |
CE: EN 50130-4 EN 55032 EN 55035 EN 61000-3-3 EN IEC 61000-3-2 EN 62368-1 NEMA 4X |
| Audio Input |
1 channel (LINE IN, bare wire) |
| Audio Output |
1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input |
2 (on-off value input: 0–5 VDC) |
| Alarm Output |
1 channel |
| Alarm Linkage |
Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light |
| Alarm Event |
Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Alarm Event |
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power Supply |
12 VDC, 3 A ± 10%;PoE (802.3at) |
| Power Consumption |
Basic: 14 W; Max: 25 W (illuminator + heating glass + Siren and Light Active Deterrence + ICR + PTZ) |
| Power Adapter |
Optional |
| Operating Temperature |
–40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity |
≤95% |
| Protection |
IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Product Dimensions |
194.2 mm × 160 mm × 311 mm (7.65" × 6.30" × 12.24") (L × W × H) |
| Net Weight |
3.1 kg (6.83 lb) |
| Gross Weight |
4.6 kg (10.14 lb) |
