| Pan/Tilt Range |
Overview channel: Pan: 0° to 360° endless; Tilt: 0° to +30°; Detail channel: Pan: 0° to 340°; Tilt: –10° to +180° |
| Manual Control Speed |
Overview channel: Pan: 0.1°/s–100°/s; Tilt: 0.1°/s–50°/s Detail channel: Pan: 0.1°/s–360°/s; Tilt: 0.1°/s–200°/s |
| Preset Speed |
Overview channel: Pan: 100°/s; Tilt: 50°/s Detail channel: Pan: 360°/s; Tilt: 200°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Scan |
5 |
| Power-off Memory |
Yes |
| Idle Motion |
Preset;Tour;Scan |
| PTZ Protocol |
DH-SD Pelco-P/D (Auto recognition) |
| IVS (Perimeter Protection) |
Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linking the Detail channel camera to track objects |
| Video Metadata |
Metadata is information on the attributes of targets that is extracted during monitoring. It can be used for data retrieval. There are four kinds of metadata supported by Dahua PTZ WizMind cameras: Human face, human body, motor vehicle and non-motor vehicle. Face information includes gender, age, glasses, masks, beards, and more. Human body information includes hat, top, top color, bottom, bottom color, bag, and more. Motor vehicle information includes plate color, type, vehicle color, sun visor, ornament, calling, seatbelt, smoking, annual inspection sticker, and more. Non-motor vehicle information includes type, color, top type, top color, people number, and more. |
| Face Detection |
Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. |
| Face Recognition |
Face attributes are extracted from captured faces, and stored in a database where they can be conveniently searched for and compared against other images. Once a successful match is found, the system outputs the result. The Dahua Face Recognition camera supports a built-in database that stores up to 10,000 face images, allowing the camera to capture and compare face images in real time. |
| Smart Tracking |
Wiztracking;Linkage Tracking |
| SMD |
SMD 4.0 |
| Quick Pick |
Yes |
| Video Compression |
Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG |
| Streaming Capability |
3 streams |
| Resolution |
Overview channel: 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 VGA (640 × 480); CIF (352 × 288/352 × 240) Detail channel: 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate |
Overview channel: Main stream: 4M/3M/1080p/1.3M/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps) Sub stream 2: 1080p/1.3M/720p@(1–25/30 fps) Detail channel: Main stream: 4M/3M/1080p/1.3M/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps) Sub stream 2: 1080p/1.3M/720p@(1–25/30 fps) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 512 Kbps–13056 Kbps H.265: 204 Kbps–7936 Kbps |
| Day/Night |
Overview channel: Auto; Color; B/W; Electronic Detail channel: Auto; Color; B/W; Electronic |
| WDR |
Overview channel: 150 dB Detail channel: 150 dB |
| White Balance |
Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D NR; 3D NR |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Overview channel: Electronic Image Stabilization (EIS) Detail channel: Electronic Image Stabilization (EIS) |
| Defog |
Overview channel: Electronic Detail channel: Electronic |
| Digital Zoom |
Overview channel: NA Detail channel: 16× |
| Image Rotation |
Overview channel: NA Detail channel: 180° |
| S/N Ratio |
Overview channel: ≥ 55 dB Detail channel: ≥ 55 dB |
| Audio Compression |
PCM;G.711a;G.711Mu;G.726;MPEG2-Layer2;G722.1;G729;G723 |
| Network Port |
RJ-45 (10/100 Base-T) |
| Network Protocol |
HTTP;HTTPS;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;QoS;FTP;UPnP;ICMP;SNMP;SNMPv1/v2c/v3(MIB-2);IGMP;ARP;RTCP;RTP;PPPoE;RTMP;TCP |
| Interoperability |
CGI;SDK;ONVIF (Profile S & Profile G & Profile T & Profile M) |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (total bandwidth: 64 M) |
| Storage |
IE9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
| Browser |
IE9 and later versions Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
| Management Software |
DMSS;IVSS;5 Series NVR;DSS7016D-I;SmartPSS Plus;ICC-B8900;DSS-C9100 |
| Mobile Client |
iOS;Android |
| Certifications |
CE-LVD:EN62368-1:2014+A11:2017 CE-EMC:EN 50130-4: 2011+A1:2014; EN 55032: 2015+A11:2020+A1:2020; EN 55035: 2017+A11:2020; EN 61000-3-3: 2013+A1:2019+A2:2021; EN IEC 61000-3-2: 2019+A1:2021+A2:2024 IP67:IEC60529:2013 IK10:IEC 60068-2-75:2014 |
| Audio Input |
1 channel (LINE IN, bare wire) |
| Audio Output |
1 channel (LINE OUT,bare wire) |
| Alarm Input |
2 channels in: supports wet contact connection (max load 5 mA 3-5 VDC); supports dry contact connection |
| Alarm Output |
1 channel out: dry contact, max load 1,000 mA 30 VDC/500 mA 50 VAC |
| Alarm Linkage |
Capture; preset; tour; recordings on SD card; alarm digital input; send email |
| Alarm Event |
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; illegal access |
| Power Supply |
36 VDC(±25%),2.23 A |
| Power Consumption |
Basic: 29.7 W Max. (Illuminator on + Intelligence on + Wiper on + Heater on + PTZ operation): 51 W |
| Power Adapter |
Included |
| Operating Temperature |
–40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity |
≤ 95% (RH) |
| Protection |
IP67;IK10;TVS 8000 V lightning proof; surge protection; voltage transient protection |
| Anti-corrosion Level |
Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. |
| Product Dimensions |
294.5 mm × 277.0 mm × 421.6 mm (11.78" × 11.08" × 16.86") (L × W × H) |
| Net Weight |
9 kg (19.84 lb) |
| Gross Weight |
13.8 kg (30.36 lb) |
