HIKVISION DS-KV8102 Plastic Villa Door Station

Plastic Villa Door Station

• Villa Door Station, Plastic, 1-ch Indoor station access
• 1.3 MP camera, IR Supplement(for I version), Visible light(for V version)
• 1 Ethernet port, RS-485, one physical button
• 4-ch alarm input,1-ch alarm output
• IP65, 12 VDC

System Parameters

• Processor- High-Performance Embedded SOC Processor
• Operation System- Embedded Linux Operation System

Network Parameters

• Ethernet- 10/100 Mbps Self-Adaptive Ethernet
• Network Protocol- TCP/IP, RTSP

Device Interfaces

• Network Interface1- RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
• I/O Input- 4
• I/O Output- 1
• RS-485- 1 RS-485 Half-Duplex Port
• USB- Plastic

General

• Power Supply- 12 VDC
• Power Consumption- ≤12 W
• Working Temperature- -40° C to +60° C (-40° F to 140° F)
• Working Humidity- 10% to 90%
• IP Protection Level- IP65
• Certification- FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
• Dimensions(L × W × H)- 164 mm × 97 mm × 54.4 mm (6.46″ × 3.82″ × 2.14″)
• Material- 24 VDC, Power Over Network Cable (DS-KAD606, DS-KAD612)
