描述
DS-1TP04I/AT
1U 4-ch POC Unit
DS-1TP04I/AT 屬海康威視閉路電視產品。傑成系統有限公司（香港防盜）為海康威視產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。選型及報價可參考閉路電視安裝。規格以原廠資料為準。
規格
Video and Audio
| Analog Video Input | 4-ch BNC interface for PoC camera |
|---|---|
| PoC Camera Input | PoC AF camera power supply distance: 200 m 75-3; 300 m 75-5 PoC AT camera power supply distance: 100 m 75-3; 200 m 75-5 Maximum power: 10 W Only Hikvision PoC cameras are supported |
| Video Output | 4-ch BNC interface for DVR |
General
| Power Supply | 48 VDC |
|---|---|
| Consumption | ≤ 6 W (not connected to PoC camera) |
| Working Temperature | -10 ºC to +55 ºC (14 ºF to 131 ºF) |
| Working Humidity | 10% to 90% |
| Chassis | 1 U |
| Dimension (W × D × H) | 319 × 203 × 46 mm (12.6 × 8.0 × 1.8 inch) |
