描述
Camera
Image Sensor: 1/8″ Progressive Scan CMOS
Min. Illumination: Color: 0.009 Lux @ (F1.2, AGC ON), 0.012 Lux @ (F1.4, AGC ON),B/W: 0.0009 Lux @ (F1.2, AGC ON), 0.0012 Lux @ (F1.4, AGC ON), 0 Lux with IR
Shutter Speed: 1/25 s – 1/100,000 s
Slow Shutter: No
DNR: 3D DNR
WDR: Digital WDR
Day & Night: IR Cut Filter
Auto-Iris: No
Lens
Aperture: F1.4
Focus: No
FOV: Single lens image: horizontal FOV 102°, vertical FOV 55°, diagonal FOV 120°,Panorama Image: horizontal field of view 180°, vertical FOV 95°
Lens Mount: M12
Focal Length: 2.8 mm, four lenses
Audio
Audio Compression: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio I/O: Yes
Image Enhancement: BLC, 3D DNR, HLC, defog, EIS (only the original mode supports)
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In (-S)
Image Settings: Rotate (only the original mode supports), saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
Max. Resolution: 8160 × 3616
Main Stream: Mode 1:,50Hz+BM52: 25fps(4096 × 1800, 3840× +BN52+BL52
Network
Protocols: Network disconnected, IP address conflict, illegal login, HDD full, HDD error
API: V5.5.70
Security: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Simultaneous Live View: ONVIF (PROFILE S, PROFILE G), ISAPI
User/Host: Up to 20 channels
Client: Up to 32 users,3 levels: Administrator, Operator and User
Web Browser: iVMS-4200
Detection: Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Firmware Version: One-key reset, anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter (only the original mode supports)
Smart Features: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Alarm: 1 Input (line in), 1 output (line out), mono sound
Video Output: 1 RJ45 10M/100M/1000M self-adaptive Ethernet port,-S: 1 RS-485
On-Board Storage: 2 Inputs, 2 outputs (max. 12 VDC, 1 A)
Reset Button: H.264 and H.265 encoding
Housing Interface: Yes
General
Power Supply: -40 °C to +60 °C (-40 °F to +140 °F), Humidity 95% or less (non-condensing)
Weight: Camera: 190 × 207 × 208 mm (7.5″ × 8.2″ × 8.2″),Package: 336 × 261 × 293 mm (13.2″ × 10.3″ × 11.5″),
Power Consumption: Non-AC: 12 VDC±20%, three-core terminal block, PoE (802.3at), class 4,-AC: 24 VAC±20%, three-core terminal block, PoE (802.3at), class 4
Accessory: IP67, IK10
Shipping Weight: Non-AC: 12 VDC, 1.4 A, max. 17 W, PoE (802.3at, 42.5 V to 57V), max. 23 W,-AC: 24 VAC, 1.2 A, 50Hz, PoE (802.3at, 42.5 V to 57 V), max. 23 W
Wiper: Aluminum alloy & plastic
Compression Standard
H.264+: No
H.265+: No
H.264 Type: Baseline Profile/Main Profile/High Profile
Video Compression: Main stream: H.265/H.264
H.265 Type: Main Profile
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Video Bit Rate: 32 Kbps to 16 Mbps
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
IR
IR Range: Four IR LEDs, up to 20 m
Wavelength: 850 nm
