Camera
Image Sensor: 1/1.8ʺ Progressive Scan CMOS
Min. Illumination: Color: 0.007 Lux @ (F1.2, AGC ON), 0.016 Lux @ (F1.8, AGC ON), 0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Yes
Angle Adjustment: Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°
WDR: 120 dB
Day & Night: IR cut filter
Lens
Aperture: 2.8 to 12 mm: F1.2 to 2.5 ,8 to 32 mm: F1.8, Constant F1.8 throughout the zoom range
Focus: Auto, semi auto, manual
FOV: 2.8 to 12 mm, horizontal FOV 112.4° to 41°, vertical FOV 58° to 23°, diagonal FOV 137° to 47° 8 to 32 mm, horizontal FOV 39° to 15.6°, vertical FOV 21.8° to 8.9°, diagonal FOV 45° to 17.8°
Lens Mount: Integrated
Lens Type: Motorized lens, 2.8 to 12 mm and 8 to 32 mm optional
Illuminator
IR Range: 2.8 to 12 mm: up to 50 m; 8 to 32 mm: up to 100 m
Wavelength: 850 nm
Video
Max. Resolution: 3840 × 2160
Video Stream: 5 defined streams and up to 5 custom stream
Main Stream: 50Hz: 25fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720) ,60Hz: 30fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 16 Mbps
H.264+: Main stream support
H.265+: Main stream support
Scalable Video Coding (SVC): H.264 and H.265 encoding
Smart Feature-Set
Smart Event: Line crossing detection, up to 4 lines configurable ,Intrusion detection, up to 4 regions configurable ,Region entrance detection, up to 4 regions configurable ,Region exiting detection, up to 4 regions configurable ,Unattended baggage detection, up to 4 regions configurable ,Object removal detection, up to 4 regions configurable ,Face detection: detects faces and upload images ,Scene change detection, defocus detection,
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Perimeter Protection: Line crossing, intrusion, region entrance, region exiting ,Support alarm triggering by specified target types (human and vehicle) ,Filtering out false alarm caused by target types such as leaf, light, animal, and flag, etc.
Image Enhancement: BLC, HLC, 3D DNR, Defog, EIS, distortion correction
Image Setting: Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping: Yes
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Network
Network Storage: microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR ,Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Smooth Streaming: Yes
Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels: administrator, operator and user
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser: Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Interface
Communication Interface: 1 RJ45 10M/100M/1000M Ethernet port
Alarm: 2 inputs, 2 outputs (max. 24 VDC/VAC, 1A)
Interface Style: Socket style interface
On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Video Out: 1Vp-p composite output (75 Ω/CVBS), only for adjustment
Firmware Version: 5.5.90
Web Client Language: 32 languages ,English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General
General Function: Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Reset: Reset via reset button on camera body, web browser and client software
Startup And Operating Conditions-30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F) Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 20%, two-core terminal block; reverse polarity protection, PoE (802.3at, class 4)
Material: Metal
Dimensions: Camera: Φ144 × 347 mm (Φ5.7″ × 13.7″) ,With package: 405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
Weight: Camera: approx. 2.45 kg (5.40 lb.) With package: approx. 2.7 kg (5.95 lb.)
Power Consumption And Current: -IZS: 12 VDC, 1.2 A, 14 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A, class 4 ,-IZHS: 12 VDC, 1.4 A, 16.5 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A, class 4
Heater: -H: yes
Storage Conditions: -30 °C to 65 °C (-22 °F to 149 °F) ,Humidity 95% or less (non-condensing)
Approval
EMC: 47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
Safety: UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry: 2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
Protection: Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
