Camera
Image Sensor: 1/3″ Progressive Scan CMOS
Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR, ,Color: 0.028Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
Day &Night: IR Cut Filter
Wide Dynamic Range: 120dB
DNR: 3D DNR
Axis Adjustment: Pan: 0° to 360°, tilt: -75° to 65°, rotate: 0° to 360°
Lens
Focal Length: 1.68 mm
Aperture: F2.0
FOV: Horizontal field of view: 180°, Vertical field of view: 85°
Lens Mount: M12
Illuminator
IR Range: Up to 10 m
Wavelength: 850nm
Video
Max. Resolution: 2304 × 1296
Main Stream: 50Hz: 20fps (2304 × 1296), 25fps (1920 × 1080, 1280 × 720),60Hz: 20fps (2304 × 1296), 30fps (1920 × 1080, 1280 × 720)
Sub Stream: 50Hz: 25fps(640 × 360, 480 × 272, 432 × 240),60Hz: 30fps(640 × 360, 480 × 272, 432 × 240)
Video Compression: Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG
H.264 Type: Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 8 Mbps
SVC: Support H.264 and H.265 encoding
Audio
Audio Compression: G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Environment Noise Filtering: Yes
Audio Sampling Rate: 16 kHz, 32kHz, 44.1kHz, 48kHz
Smart Feature-Set
Region Of Interest: Support 1 fixed region for main stream and sub-stream separately
Image Enhancement: BLC/3D DNR
Image Setting: Saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night Switch: Auto/Schedule
Wi-Fi
Wireless Standards: IEEE 802.11b/g/n
Frequency: 2.412 GHz to 2.4835 GHz
Channel Bandwidth: 20M/40M
Security: WPA, WPA2
Transfer Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
Wireless Range: 50 m
Network
Alarm Trigger: Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, illegal login
Network Storage: Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols: 802.11b: DQPSK, DBPSK, CCK,802.11g/n: OFDM/64-QAM, 16-QAM, QPSK, BPSK
API: ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View: Up to 6 channels
User/Host: Up to 32 users,3 levels: Administrator, Operator and User
Client: iVMS-4200, Hik-Connect, iVMS-5200
Interface
Audio: 1 built-in mic, 1 built-in speaker, two-way audio, mono sound
On-Board Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
General Function: One-key reset, anti-flicker, dual streams, heartbeat, password protection, privacy mask, watermark
Reset: Yes
Startup And Operating Conditions: -10 °C to +40 °C (14°F to +104 °F), Humidity 95% or less (non-condensing)
Power Supply: 5 VDC ± 10%, micro USB
Power Consumption And Current: 5 VDC, 1A, max. 6.5W
Material: Bracket: metal,Camera shell: plastic
Dimensions: Φ78.1 mm × 110.2 mm (Φ3.07″ × 4.34″)
Weight: Camera: Approx. 230 g (0.51 lb.)
Interface Protection: TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
Compression Standard
H.264+: Yes
H.265+: Yes
