HIKVISION DS-2XS6K01-C36S80 Solar Power Modules
HIKVISION DS-2XS6K01-C36S80 Solar Power Modules
- 80 W photovoltaic panel, 360 Wh chargeable lithium battery
- Support battery management, battery display, battery high-low temperature protection, charge-discharge protection, low-battery sleep protection and remote wakeup
- Water and dust resistant (IP66)
SPECIFICATIONS
Interface
- RS-4851 RS-485 (half duplex, connect to Solar Power 4G Network Camera Kit )
- Power Output9 to 12.6 VDC, max. 30 W, 2 × Ø5.5 mm coaxial power plugs
General
- Dimension640.4 mm × 735.9 mm × 760 mm (25.21″ × 28.97″ × 29.92″) (Max. size after it is completely assembled)
- Package Dimension862 mm × 352 mm × 762 mm (33.9″ × 13.9″ × 30″)
- WeightApprox. 24 kg (52.9 lb.)
- With Package WeightApprox. 30.005 kg (66.1 lb.)
Battery
- Battery TypeLithium
- Capacity360 Wh (90 Wh for each battery)
- Battery Voltage10.8 V
- Operating Temperature
Charging: -20 °C to 45 °C (-4 °F to 113 °F)
Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
- Battery LifeMore than 500 cycles
- Battery WeightApprox. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery)
Approval
- EMC
CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 50130-4:2011+A1:2014);
RCM (AS/NZS CISPR 32: 2015);
IC (ICES-003: Issue 7)
- SafetyCB (IEC 62368-1:2014+A11)
- Environment
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
- Protection
Camera: IP66 (IEC 60529-2013)
Wind resistance 12 level, up to 40 m/s wind speed resistance
