描述
DS-K6B411TX/Modular
Value Smart Swing Barriers
DS-K6B411TX/Modular 屬海康威視門禁產品。傑成系統有限公司（香港防盜）為海康威視產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合電鎖、出門掣及管理軟件一併施工。方案可參考門禁系統。規格以原廠資料為準。
規格
System
| Motor | Brushless Motor |
|---|---|
| MCBF | ≥ 5 million times |
| Brake | Not support |
| Door open duration | 5 to 60 sec |
| dToF sensor | × 6 |
Video
| Lens | Dual lens |
|---|---|
| Video compression standard | H.264 |
| Resolution | 2 MP |
| FOV | Horizontal: 75° Vertical: 139° |
| WDR | Support |
| Video standard | PAL by default, support NTSC |
Audio
| Audio compression standard | G.711U |
|---|---|
| Audio compression bitrate | 64 Kbps |
| Audio output | Support |
| Volume adjustment | Support |
| Power output | 5.5W |
Network
| Wired network | Support,10M/100M |
|---|---|
| Wi-Fi | For AP mode only |
Interface
| Network interface | 1 |
|---|---|
| Lock control | 0 |
| Exit button | 2 |
| Alarm output | 4 |
| RS-485 | 2 |
| RS-232 | 0 |
| Wiegand | 0 |
| USB | 2 |
| Fire alarm input | 2 |
| Case input | 2 |
Hardware
| Access controller | Supplied |
|---|---|
| Supercapacitor | Supplied |
| Network switch | Not supplied |
Capacity
| Face capacity | 100,000 |
|---|---|
| Card capacity | 200,000 |
| Event capacity | 100,000 |
Authentication
| Face recognition distance | 0 m to 2 m |
|---|---|
| Face recognition accuracy rate | ＞99% |
| Face recognition duration | ＜200 ms |
Function
| Configuration via PC Web | Support |
|---|---|
| Configuration via mobile Web | Support |
| Hik-Connect | Support |
| Multi-factor authentication | Support |
| Face anti-spoofing | Support |
| Built-in face recognition | Support |
| Communication protocol | ISAPI,TCP/IP |
General
| Lane width | 550 mm to 1100 mm (21.65" to 43.31") |
|---|---|
| Barrier material | 8 mm acrylic glass |
| Pedestal material | SUS304 stainless steel 1.2 mm |
| Indicator | Lane status indicator, authentication indicator and barrier light |
| Power consumption | 100 W |
| Working temperature | -15 °C to 65 °C (5 °F to 149 °F) |
| Working humidity | 10% to 95% (No condensing) |
| Protective level | IPX4 |
| Dimensions | Without package: 1205 mm × 199 mm × 1072 mm (47.44" × 7.83" × 42.21") With package: 1405 mm × 345 mm × 1195 mm (55.31" × 13.58" × 47.05") |
| Approval | CE/CB/RoHS/REACH/WEEE |
| Power supply method | M: 100-120V~/200-240V~,50Hz/60Hz,1.6A L/R: 100-240V~,50Hz/60Hz,0.8A |
| Language | English, Japanese, Thai, Indonesian, Russian, Spain (European), Spain (Latin America), Portugal (Brazil), Arabic, Kazakh, Uzbek, Ukraine |
| Interconnecting cable length | 5.5m |
Configuration
| Lane width | 650;750;900;1100 |
|---|---|
| Pedestal length | 1200 mm |
| Module selection | YES |
| Pedestal width | 200 mm |
| Wall distance | 20 mm |
| Base | YES |
| Barrier material | Acrylic glass;Stainless steel pipe |
| Application environment | Indoor and outdoor |
| Authentication mode | QR code;Face;Card |
| Card type | Desfire;EM |
| Recommended width | 650 mm |
| Base model | DS-KSM01/B411 |
| Product type | Swing barrier |
| Remote controller type | NA |
| Built-in face recognition | YES |
| Convert Face | NO |
| Door Height | Default(0.77m) |
| Door wing gap | Default:50mm |
| Integrated Auth | Card;Face |
