HIKVISION DS-KAS541 Face Recognition Terminal Kit

描述

Face Recognition Terminal Kit

  • Touch-free single-door access control solution
  • Deep learning face recognition
  • 2 mega pixel dual-lens camera
  • 4.3-inch LCD touch screen
  • Access control with multiple authentication modes
  • IP65



Specification



Face Recognition Terminal/System Parameters

  • Model : DS-K1T341CMF
  • Operating System : Linux



Face Recognition Terminal/Display Parameters

  • Screen Size : 4.3-inch
  • Operation Method : Capacitive touch screen
  • Type : LCD
  • Resolution : 480 × 800



Face Recognition Terminal/Video Parameters

  • Lens : × 2
  • Resolution : 2 MP



Face Recognition Terminal/Network

  • Wired Network : 10 M/100 M/1000 M self-adaptive



Face Recognition Terminal/Interface

  • Network Interface : 1
  • Lock Control : 1
  • Exit Button : 1
  • Door Contact Input : 1
  • TAMPER : 1
  • RS-485 : 1
  • Wiegand : 1
  • USB : 1



Face Recognition Terminal/Capacity

  • Face Capacity : 1,500
  • Fingerprint Capacity : 1,500
  • Card Capacity : 1,500
  • Event Capacity : 150,000



Face Recognition Terminal/Authentication

  • Face Recognition Distance : 0.3 to 1.5 m
  • Face Recognition Accuracy Rate : >99%
  • Face Recognition Duration : < 0.2 s
  • Fingerprint Recognition Duration : < 1 s
  • Card Type : M1 card
  • Card Reading Frequency : 13.56MHz
  • Card Reading Distance : 0 to 3 cm
  • Card Reading Duration : < 1 s



Face Recognition Terminal/Function

  • QR Code Recognition : Support
  • Face Anti-Spoofing : Support
  • Audio Prompt : Support
  • Time Synchronization : Support



Face Recognition Terminal/General

  • Button : Touch screen
  • Power Supply : 12 VDC, 2 A.
  • Working Temperature : -30 °C to 60 °C (-22 °F to 140 °F)
  • Working Humidity : 0 to 90% (No condensing)
  • Protective Level : IP65
  • Dimensions : 172.5 mm × 83.2 mm × 22.7 mm (6.79″ × 3.27″ × 0.89″)
  • Installation : Surface mounting



Magnetic Lock/General

  • Model : DS-K4H258S
  • Unlock Method : Current interruption
  • Maximum Holding Force : 280 kg (617.4 Lbs) linear thrust
  • Power Supply : 12 VDC, 340 mA
  • Indicator : Green (work status)
  • Surface Temperature : ≤ ambient temperature 20 °C (68 °F)
  • Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity : 0 to 95% (relative humidity)
  • Dimensions :

    Lock body: 238 mm × 45 mm × 25 mm (9.4″ × 1.8\” × 1.0\”)

    Armature plate: 182 mm × 38 mm × 12.5 mm (7.2 × 1.5\” × 0.5\”)”

  • Weight : 2.1 kg (4.6 Lbs)
  • Suitable Door : Wooden door, glass door, metal door, fireproof door
  • Shell Performance : Hard anodizing electroplating operated
  • Lock Body : Eco-friendly Nickel electroplating operated
  • Armature Plate : Eco-friendly Nickel electroplating operated



Card/General

  • Model : FM11RF08-M1
  • RAM : 1 K byte
  • Card Reading Frequency : 13.56 MHz
  • Card Property : Thin card
  • Function : Read/write
  • Card Reading Distance : ≤10 cm
  • Working Temperature : -20 °C to 75 °C (-4 °F to 167 °F)
  • Dimensions : 85.5 mm × 54 mm × 0.8 mm (3.37″× 2.13″ × 0.03″)
  • Weight : < 5.6 g (0.2 oz)
  • Material : PVC
  • Color : White



Bracket Of Magnetic Lock/General

  • Dimensions :

    L-bracket: 238 mm ×30 mm × 47 mm (9.4″ × 1.2\” × 1.9\”)

    Z-bracket: 185 mm ×44mm × 100 mm (7.3 ×1.7\” × 3.9\”)”

  • Model : DS-K4H258-LZ
  • Suitable Door : Wooden, metal
  • Shell Performance : Hard anodizing electroplated
  • Weight : 0.77 kg (1.7 lb)



Exit Button/General

  • Model : DS-K7P03
  • Power Supply : 12 VDC, 40 mA (standby)/70 mA (working)
  • Current Rating : 1 A@30 VDC
  • Working Temperature : -20 °C to 50 °C (-4 °F to 122 °F)
  • Working Humidity : 0 to 95% (relative humidity)
  • Dimensions : 86 mm × 86 mm × 25.7 mm (3.39″ × 3.39″ × 1.01″)
  • Weight : 0.2 kg (0.44 lb)
  • Material : Stainless steel
  • Output Contact : NO/NC/COM contact
  • Aging Test : Already passed 1 million times aging test
  • Suitable Door : All kinds of narrow doorframes
