HIKVISION Network Column Speaker 30W

HIKVISION Network Column Speaker 30W

查詢價錢

DS-QAZ1430G1

  • Adopt high-speed industrial grade dual core chips, built-in NOR Flash+EMMC dual storage, support dual backup of the system to ensure stable and reliable system performance.
  • Support secure startup, user login locking mechanism, and password complexity prompts, support security audit log traceability, and improve system network security.
  • Support batch unified management of remote platforms through IP networks (local area networks/public networks) and flexible configuration of local WEB single machines, while also support local audio collection and playback, adapting to various scene applications.
  • Support alarm input, arming schedule, and audio linkage, support TTS speech synthesis and text broadcasting, with natural and smooth standard male and female dual audio options.

此型號可由傑成系統有限公司上門安裝（保安牌照 1507）。身份為安裝商及經銷商。安裝見閉路電視安裝；保養見保養；其他公司系統維修見維修。

WhatsApp 查詢此型號 預約免費勘察
  • 持牌安裝（保安公司牌照 1507）
  • 原廠行貨，原廠保用
  • 全港免費上門勘察
分類:

描述

HIKVISION Network Column Speaker 30W

DS-QAZ1430G1



Specification

Microphone

  • Typeelectret
  • Amount2
  • Frequency Response100 Hz to 20 kHz
  • Sensitivity-42 dBV/Pa
  • Sampling Rate48 kHz
  • Quantization Bits16 bit



Speaker

  • Rated Power30 W
  • Impedance8 Ω
  • Max. Acoustic Pressure97.5 dBSPL
  • Sensitivity(1 M, 1 W)91 dB
  • DirectionAll directions
  • Frequency Response100 Hz to 20 kHz
  • SNR85 dB



Function

  • Audio AlgorithmAEC、AGC、ANS、DRC
  • Audio Bit RateG.711ulaw(64 Kbps)/G.711alaw(64 Kbps)/MP3(128 Kbps)
  • Audio File FormatMP3, WAV
  • NTP TimingSupport
  • BroadcastRegular broadcast, live broadcast, emergency broadcast
  • Two-Way AudioSupport
  • Speech SynthesisEnglish



Network

  • Network ProtocolIPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH
  • Interface Protocol (API)ISAPI, ISUP, SIP, RTP
  • ClientHik-Connect, ivms/4200, HikCentral Professional, Hik-Partner Pro, NVR, MileStone
  • Communication
  • Communication MethodSupport wired network communication
  • Interface
  • Ethernet InterfaceRJ45 10 M/100 M Adaptive Ethernet port × 1
  • Local StorageBuilt-in 4 GB EMMC (Audio file storage is 1 GB.)
  • APIISAPI, ISUP, SIP
  • AlarmAlarm input × 2
  • Audio InLine in × 1, phoenix terminal
  • LED Indicator

    Green light on: normal

    Green light flash: intercom in progress

    Red light on: start or network disconnection

    Red light flash: upgrading

  • ResetSupport



General

  • Power24 VDC/1.5A
  • MaterialMetal
  • Operating Temperature-40 °C to 60 °C(-40 °F to 140 °F)
  • Operating Humidity＜90% (No condensation)
  • Language5 languages: English, French, Spanish, German, Italian
  • Dimension160 mm × 160 mm × 292.8 mm(6.3″ × 6.3″ × 11.53″)
  • Package Dimension560 mm × 265 mm × 250 mm(22″ × 10.4″ × 9.8″)
  • WeightApprox. 3.47 kg (7.65 lb.)
  • ColorWhite
  • With Package WeightApprox. 5.14 kg (11.33 lb.)
  • Packing List

    Device × 1

    Adapter × 1

    Screw pack × 1

    Support × 1

    L-shaped wrench × 1

    Regulatory Compliance and Safety Information × 1



Approval

  • ProtectionIP66: IEC 60529-2013
  • EMCCE-EMC: EN 55032:2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7
  • Safety

    CB: IEC 62368-1:2014

    CE-LVD: EN 62368-1:2014/A11:2017

  • Environment

    CE-RoHS: 2011/65/EU

    WEEE: 2012/19/EU

    Reach: Regulation (EC) No 1907/2006
