描述
AR-0600M-270
Electronic Magnetic Lock 600LBS
AR-0600M-270 屬Soyal 碩陽門禁產品。傑成系統有限公司（香港防盜）為Soyal 碩陽產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合電鎖、出門掣及管理軟件一併施工。方案可參考門禁系統。規格以原廠資料為準。
功能重點
- If you are installing the new AR-0600M-270 on an old version (M4) L-bracket, you will need to purchase a separate conversion screw package.
- Obtained international patents for anti-drop and easy installation inventions
- Obtained international patents for anti-oxidation, anti-demagnetization, and anti-dust accumulation
- Entire lock body manufactured to UL94V0 fire resistance standard
- Reinforced lock body structure design, with side plates thickened to 8mm and screws enlarged to M5, significantly enhancing overall yield strength
規格
Electronic Magnetic Lock AR-0600M-270
| Operating Voltage | 12VDC/24VDC |
| Current Draw | 560mA/12VDC ； 280mA/24VDC |
| Lock Type | Lock Housing: Allumunium Alloy, Armature Plate: Galvanized Iron Plate, Bracket: Allumunium Alloy |
| Holding Force(kg) | 270 |
| Selenoid Test | Over 500,000 times |
| Temperature | Lock Surface: ≦ ambient temperature ± 20°C Operating:-20℃ ~ +70℃ |
| Humidity | 0~95% non-condensing |
| Dimmension (mm) | Magnet: 51(H) x 250(W) x 27(D) Armature Plate: 40(H) x 186(W) x 16(D) |
| Bracket Type | Z&L Bracket: AR-0600MZL-M5(Z and L Bracket can be purchased separately) Armature Plate Bracket (MA Bracket): AR-MA-46190 U Bracket: AR-0600M-U |
| Electronic Magnetic Lock Net Weight (kg) | approx.1.2kg |
| Door Monitoring Output | YES(Type C) |
| LED indicator | YES |
| Igress Protection (IP) | — |
