描述
Soyal AR-1200M INDOOR Electronic Magnetic Lock 1200LBS 是Soyal電鎖。香港防盜為安裝商及經銷商，負責開孔、對準門鉸、對接控制器及消防解鎖。規格以下方原廠資料為準。
相關方案：Soyal 門禁安裝、門禁系統、貨倉方案。選型可先參閱以上方案頁；原廠規格見下方。
AR-1200M
INDOOR Electronic Magnetic Lock 1200LBS。
| Operating Voltage | 12 to 24 VDC |
| Current Draw | 12VDC – 500mA 24VDC – 250mA |
| Lock Type | Lock Housing: Allumunium Alloy, Armature Plate: Pure Iron, Bracket: Allumunium Alloy |
| Holding Force(kg) | 500 |
| Selenoid Test | Over 500,000 times |
| Temperature | Lock Surface: ≦ ambient temperature ± 20°C Operating: -10°C ~ +55°C |
| Humidity | 0~95% non-condensing |
| Dimmension (mm) | Magnet: 74(H)X266(W)X40(D) Armature Plate: 61(H)X185(W)X16(D) |
| Bracket Type |
Z&L Bracket: AR-1200MZL (Z and L Bracket can be purchased separately) |
| Electronic Magnetic Lock Net Weight (kg) | approx. 3.2kg |
| Door Monitoring Output | YES(All type) |
| LED indicator | YES(All type) |
| Igress Protection (IP) | — |
數字以原廠規格書為準。
電鎖安裝、調試、保養及維修
香港防盜（持牌主體傑成系統有限公司 KNS SYSTEM LTD）為Soyal電鎖的安裝商及經銷商，保安牌照 1507、電業承辦商 029394。工作包括開孔、對準門鉸、對接控制器及消防解鎖。
查詢 2122-9527，WhatsApp 9439-8568。保養見保安系統保養。系統選型見門禁系統。Soyal安裝見Soyal 門禁安裝。
