Soyal AR-716-E16-1608R-PU IP 10-door centralized backup power controller 是Soyal門禁控制器。香港防盜為安裝商及經銷商。門數及擴展以原廠規格為準，並預留消防解鎖及 UPS。此類產品並非牆面拍卡讀頭。
相關方案：Soyal 門禁安裝、門禁系統、貨倉方案。選型可先參閱以上方案頁；原廠規格見下方。
AR-716-E16-1608R-PU
IP 10-door centralized backup power controller。
| Protocol | Modbus RTU, Soyal | ||||
| Interface | Ethernet | — | |||
| PoE | — | ||||
| Serial port | RS485 X1,Baud Rate 9600 bps – 19200 bps(N,8,1) RS485 X1 | ||||
| I/O | Input | Digital Input | — | ||
| Isolated Input | X 16 | ||||
| Fire Input | — | ||||
| Output | MosFET Output | — | |||
| Relay Output | X 8 | ||||
| Infrared | — | ||||
| Independent Power Supply |
— | ||||
| Wiegand port | — | ||||
| Watchdog | Yes | ||||
| Power Voltage | 12-24 VDC | ||||
| Power Consumption | <4W | ||||
| Surge Suppression | 400W peak power dissipation. Clamping time < 1 picosecond (theoretical) Power: bi-directional avalanche breakdown device. RS485 bi-directional avalanche breakdown device. |
||||
| Power Fuse | Power & RS485 both with PTC Protector | ||||
| Dimension (mm) | PCB | 117(H)x148(W)x20(D) | |||
| Panel Mounting Base |
117(H)x175(W)x30(D) | ||||
| Metal Box | 330(H)x250(W)x80(D) | ||||
| Net weight (g) | PCB | approx.100 | |||
| Panel Mounting Base |
approx.182 | ||||
| Metal Box | approx.1760 | ||||
| Operating Temperature | 20℃ ~ +70℃ | ||||
| LVD | EN 62368-1 | ||
| EMC | EN 55032 | ||
| EMS | IEC 61000-4-2 ESD: Contact 6kV; Air: 8kV IEC 61000-4-3 RS: 80MHz to 2.7GHz: 10V/m |
||
數字以原廠規格書為準。
控制器安裝、調試、保養及維修
香港防盜（持牌主體傑成系統有限公司 KNS SYSTEM LTD）為Soyal門禁控制器的安裝商及經銷商，保安牌照 1507、電業承辦商 029394。工作包括盤位、網絡、讀頭及電鎖對接、權限及夜間測試，並預留消防解鎖及 UPS。此類產品並非牆面拍卡讀頭。
查詢 2122-9527，WhatsApp 9439-8568。保養見保安系統保養。系統選型見門禁系統。Soyal安裝見Soyal 門禁安裝。
