LRS-100-24
100W Single Output Switching Power Supply(24V)
LRS-100-24 屬Soyal 碩陽門禁產品。傑成系統有限公司（香港防盜）為Soyal 碩陽產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合電鎖、出門掣及管理軟件一併施工。方案可參考門禁系統。規格以原廠資料為準。
功能重點
- Full-range AC input
- Protection types: short circuit/overload/overvoltage
- Can operate under conditions up to 5000 meters above sea level (Note 7)
- Can withstand 5G vibration testing
- Power-on LED indicator
- No-load power consumption <0.3W
- 100% full-load aging test
- Overvoltage category III
- High efficiency, long life, and high reliability
規格
OUTPUT
| DC VOLTAGE | 24V |
| RATED CURRENT | 4.5A |
| CURRENT RANGE | 0 ~ 4.5A |
| RATED POWER | 108W |
| RIPPLE & NOISE (max.) | 150mVp-p |
| VOLTAGE ADJ. RANGE | 21.6 ~ 28.8V |
| VOLTAGE TOLERANCE | ±1.0% |
| LINE REGULATION | ±0.5% |
| LOAD REGULATION | ±0.5% |
| SETUP, RISE TIME | 500ms, 30ms/230VAC 500ms,30ms/115VAC at full load |
| HOLD UP TIME (Typ.) | 55ms/230VAC 10ms/115VAC at full load |
INPUT
| VOLTAGE RANGE | 85 ~ 264VAC 120 ~ 373VDC (Withstand 300VAC surge for 5sec. Without damage) |
| FREQUENCY RANGE | 47 ~ 63Hz |
| EFFICIENCY (Typ.) | 90% |
| AC CURRENT (Typ.) | 1.9A/115VAC 1.2A/230VAC |
| INRUSH CURRENT (Typ.) | COLD START 50A/230VAC |
| LEAKAGE CURRENT | <0.75mA / 240VAC |
PROTECTION
| OVER LOAD | 110 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed |
| OVER VOLTAGE | 28.8 ~ 33.6V Protection type : Shut down o/p voltage, re-power on to recover |
ENVIRONMENT
| WORKING TEMP. | -30 ~ +70℃ |
| WORKING HUMIDITY | 20 ~ 90% RH(non-condensing) |
| STORAGE TEMP., HUMIDITY | -40 ~ +85℃, 10 ~ 95% RH(non-condensing) |
| TEMP. COEFFICIENT | ±0.03%/℃ (0 ~ 50℃) |
| VIBRATION | 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes |
| OVER VOLTAGE CATEGORY | Ⅲ; Compliance to BS EN/EN61558, BS EN/EN50178, BS EN/EN60664-1, BS EN/EN62477-1; altitude up to 2000 meters |
| DIMENSION | 129(H)x97(W) x30(D) |
