描述
DS-3WAP6230Q-EI/H
Wi-Fi 6 3000M Ceiling Access Point
DS-3WAP6230Q-EI/H 屬海康威視網絡傳輸產品。傑成系統有限公司（香港防盜）為海康威視產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。方案可參考網絡工程。規格以原廠資料為準。
規格
General
| Net Weight | 0.46kg (1.01 lb) |
|---|---|
| Gross Weight | 0.63kg (1.39 lb) |
| Installation Mode | Ceiling-Mount, Wall-Plate |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 10% to 90% (no condensation) |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Storage Humidity | 5% to 95% (no condensation) |
| Product Dimensions (W × H × D) | φ220*42mm (with mounting bracket) |
| Packing List | 3000 M Access Point ×1, Screw Pack × 1, Installation bracket x 1, Quick Start Guide ×1, Regulatory Compliance and Safety Information × 1 |
| Power Supply Method | DC power supply: 12 V, 2 A; PoE power supply: IEEE 802.3at; |
| Power Consumption | Standby Power Consumption: 5.5W Typical Power Consumption: 11W Maximum Power Consumption: 18W |
Wireless Parameter
| Wireless Speed | Max.: 2976 Mbps; 2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps; |
|---|---|
| Wireless Standard | Wi-Fi 6 |
| Working Frequency Band | Radio 1: 5G (11a/n/ac/ax); Radio 2: 2.4G (11b/g/n/ax); |
| Bandwidth | 2.4G: Auto/20/40 MHz 5G: Auto/20/40/80/160 MHz |
| Recommended Coverage Range | Recommended Coverage Range: 250 m², the radius in an open environment is 50 meters in omni-directional antenna mode, 150 meters in directional antenna mode. Note: The signal coverage range is greatly affected by the environment. For example, walls, glass doors, and other obstacles will affect the signal coverage. The above – mentioned values are for reference only. |
| Modulation | OFDM: BPSK @ 6/9 Mbps, QPSK @ 12/18 Mbps, 16-QAM @ 24 Mbps, 64-QAM @ 48/54 Mbps DSSS: DBPSK @ 1 Mbps, DQPSK @ 2 Mbps, and CCK @ 5.5/11 Mbps MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM and 1024-QAM OFDMA |
| Max. Number of Connected Clients | 256 |
| Recommended Number of Connected Clients | 110 |
| Transmitting Power | 2.4G Combined Power: 27dBm (24dBm per chain); 5G Combined Power: 29dBm (24dBm per chain); Note: Transmitting power may vary with local regulations. |
| Wireless Security | WPA2-PSK,WPA-WPA2-PSK,WPA3-PSK,WPA2-WPA3-PSK; |
| Antenna | 2.4 GHz: 2 built-in omnidirectional antennas, 2 built-in directional antennas 5 GHz: 3 built-in omnidirectional antennas, 2 built-in directional antennas |
| Antenna Gain | Omnidirectional: 2.4 GHz: 3.6 dBi, 5 GHz: 4.5 dBi; Directional: 2.4 GHz: 7 dBi, 5 GHz: 8 dBi; |
| RF Design | Dual-radio 4 spatial streams 2.4G: 2 × 2, MU-MIMO 5G: 2 × 2, MU-MIMO |
| FEM | 2.4 GHz: 2 x eFEM 5 GHz: 3 x eFEM |
Hardware Specifications
| Ports | 1 × Gigabit RJ45 port, 1 × 2.5G RJ45 port |
|---|---|
| RESET | 1 × Reset button |
Software Specifications
| Max. Number of Wireless SSIDs | 8 |
|---|---|
| Internet Access Mode | DHCP; Static IP; |
| VLAN ID Range | 1-4000 |
| Max. Number of VLANs | 8 |
Software Features
| Operation Mode | AP mode (default); Routing mode; |
|---|---|
| Wireless Management | Support wireless configuration; Support RF configuration; Support health mode; Support guest SSID; Support wireless 802.11k/v/r roaming; Support wireless optimization; Support wireless SSID speed limit; Support wireless RF speed limit; Support wireless intelligent speed limit; Support wireless terminal speed limit; Support weak-signal access control; Support weak-signal disassociation; Support roaming sensitivity adjustment; Support wireless access control; Support wireless terminal correlation; Support Band steering; Support AP load balancing; Supports airtime scheduling (ATF); Support smart antenna technology (beamforming), improving the signal's strength on clients; Support Wireless MESH; Support LeaderAP; Support Layer 2 Isolation; Support 5G Priority; |
| Interface | Support uplink port VLAN; Support MAC address modification; Support LAN configuration; Support port VLAN; Support QoS; |
| IP Services | Support DHCP client; Support DHCP sever; Support LLDP; Support SADP; |
| Portal Authentication | Support Portal Authentication; |
| Service and Support | Support Audit Log; Support Fault Diagnosis; Support Fault Alarm; Support One-Click Fault Collection; Support Network Diagnostic Tools; Support SSH; Support Cloud Service Diagnosis; Support Local Upgrade; Support Online Upgrade; Support Cloud Service; Support App Management; Support CAPWAP DTLS encryption; |
Approval
| EMC | CE-EMC (EN 55032: 2015+A11:2020+A1:2020 EN 61000-3-3: 2013+A1:2019+A2:2021 EN IEC 61000-3-2: 2019+A1:2021+A2:2024 EN 50130-4: 2011+A1:2014 EN 55035: 2017+A11:2020) |
|---|---|
| Safety | CB (IEC 62368-1: 2018), CE-LVD (EN IEC 62368-1: 2020+ A11: 2020) |
| Chemistry | CE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No.1907/2006) |
| Radio | EN 300 328, EN 300 440, EN 301 893, EN 301 489-1, EN 301 489-3, EN 301 489-17, EN 61000-3-3: 2013+ A1:2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021+A2: 2024, EN IEC 62311: 2020 |
