BELDEN 8403
Microphone Cable, 3 C #20 Str TC, Rayon & 90% TC Braid, PVC Jkt
Product Description
Microphone Cable, 3 Conductor 20 AWG (19 x 32) Tinned Copper (High conductivity), PE Insulation, Rayon Braid, 90% Tinned Copper Braid Shield, PVC Jacket
Technical Specifications
| Insulation | ||||
| Element | Material | Nom. Thickness | Nom. Insulation Diameter | Color Code |
| Conductor(s) | PE – Polyethylene | 0.016 in (0.41 mm) | 0.069 in (1.8 mm) | Clear, Black, Red |
| Outer Shield | ||||
| Shield Type | Material | Coverage | ||
| Braid | Rayon® | 90% | ||
| Braid | Tinned Copper (TC) | 90% | ||
| Outer Jacket | ||||
| Material | Nom. Thickness | Nom. Diameter | ||
| PVC – Polyvinyl Chloride | 0.033 in (0.84 mm) | 0.244 in (6.20 mm) | ||
