> Barriers will be closed automatically if no one entered the turnstile after the identity is verified
> Parameters can be restored to default settings.
> The locking and unlocking of barriers can be controlled by remote controller (optional).
> Support second unlock (unlock inside the passage) and memory mode.
> Support 4 types of security settings.
> The turnstile can stay open during fire emergency.
> Support mechanical and IR anti-pinch, and anti-collision.
> Support sound and light alarm, volume adjustment and various sound types.
> 9 passing modes: Pass with identity verified, not allowed to pass, and pass without restrictions, and you can use the three modes in any combination.
> Support adjusting unlocking and locking speed, pass duration, and locking delay duration
> Support alarms of intrusion (entering and exiting), tailing, overstay, climbing, abnormal unlocking, abnormal barriers, abnormal IR, abnormal communication, and more
> Support multiple authentication methods using face, fingerprint, QR code, CPU card reader/ID card reader and other modules.

Basic

Dimensions

1500 mm × 200 mm × 980 mm (59.06″ × 7.87″ × 38.58″) (L × W × H)

Surface Texture

Ink brushed

Casing

SUS304

Barrier

Acrylic or stainless steel

Motor

DC brushless servo motor

IR Detector

12 pairs

Function

Anti-collision

Yes

Anti-pinck

Yes

Memory Mode

Yes

Anti-tailing

Yes

Sound & Light Alarm

Yes

People Counting

Yes

Alarm

Yes

Second Unlock

Yes

Performance

Lock/Unlock Speed

0.5–1.6 s (adjustable)

Pass Duration

2–60 s (adjustable)

Lock Delay Duration

0–60 s (adjustable)

MCBF

≥5 million times

Passing Frequency

20–60 people/minute

Passage Width

Standard: 600 mm Max: 1100 mm

General

Net Weight

75 kg (165.35 lb) (single-motor), 95 kg (209.44 lb) (double-motor)

Gross Weight

95 kg (209.44 lb) (single-motor), 115 kg (253.53) (double-motor)

Power Consumption

Single-motor module turnstile: ≤10W (standby), ≤130W (working) Double-motor module turnstile: ≤20W (standby), ≤260W (working)

Packaging

Wooden box

Operating Temperature

–25°C to 70°C (–13°F to 158°F)

Operating Humidity

5%–90% (non-condensing)

Operating Environment

Indoor and outdoor
