Dahua ASI2212J-D Access Standalone

描述

Dahua Single Door Password, ID Card, Fingerprint Access Standalone

> 2.4″ TFT display screen with a resolution of 240 × 320.

> Audio prompts.

> Supports 5,000 users, 5,000 cards, 5,000 passwords, 3,000 finger prints, and 100,000 records.

> The security module expansion is supported to enhance security and protect against the device being opened during a power failure.

> Fingerprint/card/remote/password unlock and unlock through their combinations.

> Supports duress alarm, tamper alarm, intrusion alarm, door contact timeout alarm, illegal card exceeding threshold alarm, illegal password exceeding threshold alarm, external alarm and anti-passback alarm.

> Supports guest users, patrol users, blocklist users, VIP users, general users, and others.

> TCP/IP communication; auto registration, P2P registration, and DHCP.

> Supports online update and USB update.

System

Main Processor

Embedded Processor

Button Type

Mechanical

Network Protocol

UDP; TCP; IPv4; P2P

OSDP Protocol

Yes

Interoperability

ONVIF; CGI

SDK and API

Yes

Basic

Product Type

Standalone

Display Screen

2.4″ LCD

Screen Type

LCD

Screen Resolution

240 (H) × 320 (V)

Voice Prompt

Yes

Backlight

Yes

Casing Material

PC+ABS

Function

Verification Method

Configuration of card, remote, password, fingerprint combination unlock and multi-user combination unlock

Unlock Mode

Card, remote, password, fingerprint unlock, unlock through their combinations and multi-user combination unlock.

Card Type

ID cards

Period List

128 periods

Holiday Period

128 periods

Network Update

Yes

First User Unlock

Yes

Remote Verification

Yes

Restricted List/Trusted List

Yes

Peripheral Card Reader

1 × RS-485 card reader
1 × Wiegand card reader

Multi-user Authentication

Yes

Multi-factor Authentication

Yes

Web Configuration

Yes

Auto Registration

Yes

Performance

Card Reading Distance

0 cm–6 cm (0″–2.36″)

Fingerprint Sensor Type

Optical

Fingerprint Verification Mode

1:N

Fingerprint Comparison Time

1 s

User

User (Card) Type

Normal user; VIP users; patrol users; guest user; blocklist user; other user

Capacity

User Capacity

5000

Fingerprint Capacity

3000

Card Capacity

5000

Password Capacity

5000

Record Capacity

100,000

Port

RS-485

1

Wiegand

1

USB

1 × USB 2.0

Network Port

1 × RJ-45 100 Mbps self-adaptive Ethernet port

Alarm Input

2

Alarm Output

2

Alarm Linkage

Yes

Doorbell

1

Exit Button

1

Door Status Detection

1

Lock Control

1

Alarm

Anti-pass Back

Yes

Tamper Alarm

Yes

Duress Alarm

Yes

Door Sensor Timeout

Yes

Intrusion

Yes

Illegal Card Exceeding Threshold

Yes

Duress Fingerprint

Yes

General

Power Adapter

Optional

Power Supply

12 VDC
(the device can provide power to the lock)

Power Consumption

≤12 W

Product Dimensions

205 mm × 86 mm × 30 mm (8.07″ × 3.38″ × 1.18″) (H × W × W)

Packaging Dimensions

254 mm × 131 mm × 75 mm (10.00″ × 5.16″ × 2.95″) (H × W × W)

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

0%–95% (RH), non-condensing

Operating Altitude

0 m–3,000 m (0 ft–9842.52 ft)

Operating Environment

Indoor

Gross Weight

0.45 kg (0.99 lb)

Installation

Surface Mount

Certifications

CE; FCC

Installation Angle

Straight
