Dahua ASI7214S-W Face Recognition Access Controller
Dahua ASI7214S-W Face Recognition Access Controller：圖片 2
Dahua ASI7214S-W Face Recognition Access Controller：圖片 3
Dahua ASI7214S-W Face Recognition Access Controller：圖片 4

Dahua ASI7214S-W Face Recognition Access Controller

查詢價錢

此型號可由傑成系統有限公司上門安裝（保安牌照 1507）。身份為安裝商及經銷商。安裝見閉路電視安裝；保養見保養；其他公司系統維修見維修。

WhatsApp 查詢此型號 預約免費勘察
  • 持牌安裝（保安公司牌照 1507）
  • 原廠行貨，原廠保用
  • 全港免費上門勘察
分類: , , , , 標籤: , ,

描述

Dahua ASI7214S-W Face Recognition Access Controller 是大華人面門禁終端。香港防盜為安裝商及經銷商。須現場測試安裝高度、光線及私隱告示。規格以下方原廠資料為準。

相關方案：大華門禁安裝、門禁系統、辦公室方案。選型可先參閱以上方案頁；原廠規格見下方。

Dahua Face Recognition,Card Swiping,Password,Fingerprint Face Recognition Access Controller

> 7″ LCD with a resolution of 1024 × 600.

> The 2-MP dual-lens CMOS camera and high-performance image sensor ensure accurate recognition even in poor lighting and dark locations that lack illumination.

> Features auto illumination to effectively reduce light pollution.

> Supports 50,000 users (up to 50 administrators), 50,000 faces, 50,000 passwords, 100,000 cards, 10,000 fingerprints and 300,000 records.

> Multiple unlock methods including face, IC card, password, fingerprint and QR code. You can also combine them to create your own personal unlock methods.

> Displays the face bounding box and detects the face that occupies the most pixels in real time. You can also set target face filtering by configuring the face pixel threshold.

> Recognizes faces 0.3 m to 2.0 m away (0.98 ft–6.56 ft), and detects persons between the height of 0.9 m and 2.4 m (2.95 ft–7.87 ft) when the camera is installed 1.4 m above the ground.

> Powered by the face recognition deep learning algorithm, the device can accurately locate over 360 key points on the face of a target.

> Faces can be recognized within 0.2 seconds, without need for the person to touch the device.

> Features face mask detection and safety helmet detection.

> Multiple display modes and voice prompts are available for broadcasting recognition results to protect the privacy of users.

> Features face mask detection and safety helmet detection.

> Liveness detection is used to detect spoof attempt, such as using a photo or video to gain access.

> Offers multiple types of alarms such as duress, tamper, intrusion, unlock timeout, and excessive use of illegal card and password.

> Supports different types of users, including general, patrol, blocklist, VIP, guest and other.

> Supports making video calls with indoor monitors, the master station, and mobile app.

> TCP/IP and Wi-Fi connection, auto registration, P2P registration, and DHCP.

> Supports beautifying faces.

> Recognizes up to 6 faces at the same time.

> Plays advertisements in video and image format.

> Online update and update through USB.

> Connects to DSS Pro and SmartPSS Lite.

Specifications

System

Main Processor

Embedded Processor

Network Protocol

UDP; TCP; IPv4; RTSP; SIP; P2P; RTP

OSDP Protocol

Yes

Interoperability

CGI;ONVIF

SDK and API

Yes

Basic

Product Type

Standalone

Display Screen

7″ LCD

Screen Type

Capacitive Touchscreen

Screen Resolution

600 (H) × 1024 (V)

Camera

2-MP dual-lens CMOS camera

WDR

DWDR

Light Compensation

Auto IR

Voice Prompt

Yes

Casing Material

Tempered glass/PC

Function

Verification Method

Card; remote; password; fingerprint; face; combination unlock

Card Type

IC card

Period List

128 periods

Holiday Period

128 periods

Network Update

Yes

First User Unlock

Yes

Remote Verification

Yes

Restricted List/Trusted List

Yes

Wi-Fi

Yes

Wireless Standard

802.11b/g/n

Wireless Frequency Range

2.400 GHz–2.472 GHz

Advertisement Playing

Support graphic advertisement play

Peripheral Card Reader

Supports 1 × RS-485 card reader;
1 × Wiegand card reader

Multi-user Authentication

Yes

Real-time Monitoring

Yes

Multi-factor Authentication

Yes

Capture Function

Yes

Web Configuration

Yes

Auto Registration

Yes

Performance

Card Reading Distance

0 cm–3 cm (0″–1.18″)

Face Recognition Height Range

0.9 m–2.4 m (2.95 ft–7.87 ft)

Face Recognition Distance

0.3 m–2.0 m (0.98 ft–6.56 ft)

Face Recognition Accuracy

99.9%

Face Recognition Time

0.2 s

Fingerprint Sensor Type

Capacitive

Fingerprint Verification Mode

1:N

Fingerprint Comparison Time

1.5 s

Fingerprint Recognition Time

0.5 s

Supported Codes

QR code

Code Type

Electronic code; printed code

User

User (Card) Type

General users, patrol users, blocklist users, VIP users, guest users, custom user 1, custom user 2, and other users

Capacity

User Capacity

50000

Face Image Capacity

50000

Fingerprint Capacity

10000

Card Capacity

100000

Password Capacity

50000

Record Capacity

300000

Port

RS-485

1

RS-232

1

Wiegand

1 (input or output)

USB

1 × USB 2.0 port

Network Port

1 × RJ-45 10/100 Mbps Ethernet port

Alarm Input

2 (digital quantity)

Alarm Output

1 (relay)

Alarm Linkage

Yes

Exit Button

1

Door Status Detection

1

Lock Control

1

Alarm

Anti-pass Back

Yes

Tamper Alarm

Yes

Duress Alarm

Yes

Door Sensor Timeout

Yes

Intrusion

Yes

Illegal Card Exceeding Threshold

Yes

Duress Fingerprint

Yes

General

Power Adapter

Included

Power Supply

12 VDC, 2 A

Power Consumption

≤24 W

Product Dimensions

218 mm × 118 mm × 24.2 mm (8.58″ × 4.65″ × 0.95″) (H × W × D)

Packaging Dimensions

Carton: 299 mm × 164 mm × 72 mm (11.78″ × 6.46″ × 2.83″) (H × W × D)
Protection box: 390 mm × 320 mm × 360 mm (15.35″ × 12.60″ × 14.17″) (H × W × D)

Operating Temperature

–20 °C to +55 °C (–4 °F to +131 °F)

Operating Humidity

0%–90% (RH), non-condensing

Operating Altitude

0 m–1,300 m (0 ft–4,265.09 ft)

Operating Environment

Indoor

Gross Weight

0.67 kg (1.48 lb)

Accessory

Included: Wall mount bracket

Installation

Turnstile Mount; 86 case mount; wall; floor bracket mount

人面門禁安裝、調試、保養及維修

香港防盜（持牌主體傑成系統有限公司 KNS SYSTEM LTD）為大華人面門禁的安裝商及經銷商，保安牌照 1507、電業承辦商 029394。工作包括安裝高度、開孔、走線、對接電鎖／出門掣、權限及夜間測試；現場測試光線及私隱告示。保養包括鏡頭清潔、人面庫備份。

查詢 2122-9527，WhatsApp 9439-8568。保養見保安系統保養。系統選型見門禁系統。大華安裝見大華門禁安裝。
