System Parameter

Operating System

Embedded LINUX operating system

Network Protocol

IPv4, FTP, RTSP, RTP, TCP, UDP, SIP

Keyboard Type

Touch keyboard (0–9, *, #)

Basic Parameter

Screen Type

Capactive screen

Display

10-inch TFT LCD

Resolution

1024 (H) × 600 (V)

Video Compression

H.264

Audio Compression

G.711a, G.711Mu, G.711u, PCM

Audio Input

1 channel all-direction microphone

Audio Output

1 channel

Audio Mode

Support dual-way bidirectional talk

Audio Enhancement

Support echo suppression/DNR

Function Parameter

Communication Mode

Full digital

Leave Videos or Text Messages

Support

DND Mode

Support

Sub-station Quantity

9

Edge Storage

Embedded 8 GB

Port

Alarm Input

6 channels

Alarm Output

1 channel

Doorbell

Supported by every channel

Network

1 RJ-45, 10 M/100 Mbps self-adaptive

Alarm Parameter

SOS Alarm

Support

General Parameter

Casing

PC+ABS

Appearance Color

Black

Power Supply

Standard PoE
DC 12V 1A

Power

Optional

Installation

Surface

Certifications

CE/FCC

Dimensions

260 mm × 170 mm × 28 mm (10.24″ × 6.69″ × 1.10″)

Operating Temperature

-10°C to +55°C (+14°F to +131°F )

Operating Humidity

10%RH–90%RH (No condensation)

Power Consumption

≤7W (Work)
