描述
VTO6222E-P
2-wire IP Apartment Door Station
VTO6222E-P 屬大華視像對講產品。傑成系統有限公司（香港防盜）為大華產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。方案可參考視像對講系統。規格以原廠資料為準。
規格
System
| Main Processor |
Embedded Processor |
| Operating System |
Embedded Linux OS |
| Button Type |
Mechanical |
| Number of Buttons |
16 |
Basic
| Screen Type |
Non-touchscreen |
| Display Screen |
2.3-inch display screen |
| Camera |
1/2.9" 2 MP CMOS |
| Field of View |
H:140°,V:80°, D:160° |
| WDR |
120 dB |
| Noise Reduction |
3D NR |
| Video Compression |
H264，H265 |
| Video Resolution |
Main stream: 720p,WVGA, D1, CIF Sub stream: 1080p,WVGA, D1, QVGA, CIF |
| Video Frame Rate |
25 fps |
| Light Compensation |
Auto white light |
| Day/Night |
Color/B/W |
| Audio Compression |
G.711a, G.711u, PCM |
| Audio Input |
1 |
| Audio Output |
Built-in Speaker |
| Audio Mode |
Two-way audio |
| Audio Enhancement |
Echo suppression/digital noise reduction |
| Audio Bit Rate |
16 KHz, 16 bit |
Function
| Communication Mode |
Digital 2-wire |
| Verification Method |
Card;Password;Remote |
| Card Type |
IC card |
| Auto Snapshot |
Yes (SD card is inserted in the indoor monitor or door station) |
| Leave Videos |
NA;Yes (SD card is inserted in the indoor monitor or door station) |
| Storage |
Supports Micro SD card (up to 256 GB) |
| Web Configuration |
Yes |
RFID
| Modulation Type |
ASK |
| Frequency Range |
13.56 MHz |
| Max. Transmission Power |
42dBuA/m @10m |
Performance
| Card Reading Distance |
0 cm–3 cm (0"–1.18") |
| Casing Material |
Aluminum |
Capacity
Port
| RS-485 |
1 |
| Wiegand |
1 |
| Alarm Input |
1 |
| Alarm Output |
1 |
| Power Output |
1 port,12 V/600 mA |
| Door Bell |
1 |
| Exit Button |
1 |
| Lock Control |
1 |
| Network Port |
1 × RJ-45 port，10Mbps/100Mbps network port |
Alarm
General
| Appearance Color |
Silver |
| Power Supply |
48 VDC, 0.4 A, PoE (802.3af/at) |
| Power Adapter |
Optional |
| Installation |
Flush Mount;Surface Mount |
| Certifications |
CE |
| Accessory |
Flush mount box (optional); Surface mount box (optional) |
| Product Dimensions |
200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39") (H × W × D) |
| Protection |
IK08, IP65 (silicone sealant is needed, see the quick start guide) |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140°F) |
| Operating Humidity |
10%–90% (RH), non-condensing |
| Operating Environment |
Outdoor |
| Operating Altitude |
Beneath 3000 m (9842.52 ft) |
| Power Consumption |
≤ 5 W (standby), ≤ 7 W (working) |
| Gross Weight |
0.657 kg (1.45 lb) |
| Storage Temperature |
0 °C to +40 °C (+32 °F to +104 °F) |
| Storage Humidity |
30%–75%(RH) |
