EverFocus EHA1281
2-Megapixel True Day/Night Outdoor IR Bullet Camera
Features
- 1/2.8” 2.1 Mega-pixel Sony CMOS , delivering amazing high sensitivity
- Varifocal 2.8-12mm with ICR to capture the desired field of view
- Extended IR range of up to 40m / 131ft. with 8 LEDs (depends on scene IR reflectivity)
- D-WDR to improve the visibility under high contrast scene
- The flexible angle viewing with its 3-Axis rotation design allows wall or ceiling mounting
- IP66-rated with metal housing
- Supports dual power (12VDC / 24VAC)Supports UTC function: Control camera OSD settings directly from DVR end
Specifications
| Pickup Device | 1/2.8”,2.0Megapixel,Progressive scan,CMOS |
| System Format | NTSC / PAL (switchable via OSD) |
| Effective Pixels | 1920 (H) x 1080 (V),(can adjust to 720P) |
| Scanning System | Progressive Scan |
| Electronic Shutter | 1/30s ~ 1/30000s |
| Gamma Correction | 0 / 0.25 / 0.75 /1 |
| Lens Type | 2.8-12mm lens with ICR, F1.4 |
| FOV (D x H x V) | 105~48° x 89~42° x 50~24° |
| BLC | Level/Area/Default/Return |
| AGC | Auto |
| White Balance | ATW/AWC/AWB/Manual |
| Sync. Mode | Internal |
| Day / Night | IR Cut Filter with auto switch (Auto/Color/B&W) |
| UTC Function | Supported |
| IR LEDS | 30 Units |
| IR Distance | Up to 30m / 98ft. (Depends on scene IR reflectivity) |
| Video Format | AHD / TVI / CVI / CVBS |
| S/N Ratio | ≥50dB |
| OSD Languages | English / German / French / Polish, Russian / Portuguese / Turkish |
| DNR | Middle / High / Off / Low |
| DWDR | Off/On |
| SensUp | Off / x2 / x4 / x8 / x10/ x15 / x20 / x25/x30 |
| Frame Rate | 50Hz: 25fps/1920*1080; 60Hz: 30fps/1920*1080 |
| Mirror / Flip | Off / On (V-Flip /Rotate) |
| Motion Detection | Supported |
| Privacy Mask | Supported |
| Environmental | IP66 Weather Resistant |
| Power Source | Dual Power (12VDC/24VAC~) |
| Max. Power Consumption | 7W (12VDC / 24VAC~) |
| Operating | -20°C ~ 50°C / -4°F ~ 122°F |
| Humidity | Less than 95% |
| Dimensions | 140mm x 126.7mm |
| Weight | 1200g / 2.65lb |
| Minimum Illumination | Color:[email protected] AGC On; 0 Lux with IR On |
