HID Proximity MiniProx Hazardous Location 5365
125 kHz Mullion Mount Proximity Card Reader
- Accepts 5 to16 volts, meeting most voltage requirements.
- Available with Wiegand or Clock-and-data interface.
- Allows easy upgrade from magstripe to a proximity reader; no rewiring or pulling of new cable required.
- Offers high reliability, consistent read-range and low power consumption in an easy-to-install package.
- Mounts directly onto metal with no change in read range performance.
- Provides multicolor LED, compatibility with all standard access control systems and internal or host control of LED and beeper.
- Rated Hazardous Locations Class I, Div. 2, Groups A,B,C,D. (US, and Canada)
SPECIFICATIONS
Typical maximum* read range:
- ProxCard® II card – up to 5.5″ (14 cm)
- ISOProx® II card – up to 5″ (12.5 cm)
- ProxKey™ II keyfob – up to 2″ (5 cm)
- ProxCard® Plus card – up to 2″ (5 cm)
- SmartProx™ II card – up to 5″ (12.5 cm)
*Depending on local installation conditions.
Dimensions:
- 6.0″ x 1.7″ x 1.0″
- (15.2 x 4.3 x 2.54 cm)
Material
Polycarbonate UL 94
Power supply:
- Standard MiniProx: 5.1-16 VDC
- Haz. Loc. MiniProx: 5.1-16 VDC
- Linear power supplies are recommended.
Current requirements:
- Average: 40 mA (5 VDC); 50 mA (12 VDC)
- Peak: 60 mA (5 VDC); 120 mA (12 VDC)
Operating temperature
-22º to 150º F (-30º to 65º C)
Operating humidity
0-95% relative humidity non-condensing
Weight:
- With terminal strip 3.5 oz. (99 gm)
- With pigtail 3.8 oz. (108 gm)
- Haz. Loc. MiniProx: 3.8 oz. (108 gm)
Transmit frequency
125 kHz
Excite frequency
125 kHz
Certifications:
- Canada/UL 294 Listed: Access Control System Units
- Canada/UL 1604 Listed (with Haz. Loc. junction box only):
- Hazardous Locations Class I, Div. 2, Groups A,B,C,D.
- FCC Certification, United States
- Canada Certification
- CE Mark, Europe
- UK Type Approval
- Germany Type Approval
- Australia C-Tick Mark
- New Zealand EMC
Cable distance:
- Wiegand interface: 500 feet (150 m)
- Clock-and-data interface: 50 feet (15 m)
- Recommended cable is ALPHA 1295 (22 AWG) 5 conductor minimum stranded with overall shield or equivalent. Additional conductors may be required for LED or beeper control.
