描述
Camera
- Image Sensor：1/3″ Progressive Scan CMOS
- Max. Resolution：2688 × 1520
- Min. Illumination：Color: 0.003 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR
- Day & Night：IR cut filter
- Shutter Time：1/3 s to 1/100,000 s
- Angle Adjustment：Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
- Focal Length & FOV：2.8 to 12 mm, horizontal FOV 108° to 30°, vertical FOV 56° to 17°, diagonal FOV 131° to 35°
- Lens Type：Varifocal lens, motorized lens, 2.8 to 12 mm
- Aperture：F1.4
- Lens Mount：Ø14
- Iris Type：Fixed
DORI
DORI：2.8 to 12 mm:
Wide: D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m
Tele: D: 190 m, O: 75.4 m, R: 38.0 m, I: 19.0 m
Illuminator
- IR Wavelength：850 nm
- Supplement Light Range：Up to 60 m
- Smart Supplement Light：Yes
- Supplement Light Type：IR
Video
- Main Stream：
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream：
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream：
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360),
*Third stream is supported under certain settings.
- Video Compression:
Main stream：H.265/H.264/H.265+/H.264+,
Sub-stream：H.265/H.264/MJPEG,
Third stream：H.265/H.264
- Video Bit Rate：32 Kbps to 8 Mbps
- H.264 Type： Baseline Profile,Main Profile,High Profile
- H.265 Type： Main Profile
- Bit Rate Control：CBR,VBR
- Scalable Video Coding (SVC)：H.264 and H.265 encoding
- Region Of Interest (ROI)：1 fixed region(s) for main stream and sub-stream
Audio
- Environment Noise Filtering：Yes
- Audio Sampling Rate：8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Audio Compression：G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC
- Audio Bit Rate：64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
Network
- Protocols：TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
- Simultaneous Live View：Up to 6 channels
- API：Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
- User/Host：
Up to 32 users
3 user levels: administrator, operator, and user
- Security：Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Network Storage：
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- Clienti：VMS-4200,Hik-Connect,Hik-Central
- Web Browser：
Plug-in required live view: IE 10+,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+,
Local service: Chrome 57.0+, Firefox 52.0+
- Wide Dynamic Range (WDR)：120 dB
- SNR：≥ 52 dB
- Privacy Mask：4 programmable polygon privacy masks
- Day/Night Switch：Day,Night,Auto,Schedule
- Image Enhancement：BLC,HLC,3D DNR
- Image Parameters Switch：Yes
- Image Settings：Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Interface
- Alarm：1 input, 1 output (max. 24 VDC, 1 A)
- Audio：
1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
- Ethernet Interface：1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage：Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- Reset Key：Yes
Event
- Basic Event：Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Smart Event：Line crossing detection, intrusion detection, region entrance detection, region exiting detection, scene change detection
- Linkage：Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,audible warning
Deep Learning Function
- Face Capture：Yes
General
- Power：
12 VDC ± 25%, 1.08 A, max. 13 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.36 A to 0.27 A, max. 15 W
- Material：ADC12
- Dimension：105 mm × 105 mm × 297.9 mm (4.1″ × 4.1″ × 11.7″)
- Package Dimension：385 mm × 190 mm × 180 mm (15.2″ × 7.5″ × 7.1″)， Approx. 1355 g (3 lb.)
- With Package Weight：Approx. 2011 g (4.4 lb.)
- Storage Conditions：-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup And Operating Conditions：-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Web Client Language：33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General Function：Heartbeat,anti-flicker,mirror,flash log,password reset via email,pixel counter,privacy mask
Approval
- EMC：
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015
- Safety：
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
LOA: IEC/EN 60950-1
- Environment：
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- Protection：IP67: IEC 60529-2013;IK10: IEC 62262:2002
- Anti-Corrosion Protection：NEMA 4X (NEMA 250-2018)
