Description
Camera
Image Sensor: 1/3″ Progressive Scan CMOS
Shutter Speed: 1/25 s to 1/10,000 s
Angle Adjustment: Tilt: 0° to 45°
Digital Noise Reduction: 3D DNR
Auto-Iris: Manual
Lens
Aperture: 2.8 mm: F2.0 4 mm: F2.2
FOV: 2.8 mm: horizontal FOV 83°, vertical FOV 68° 4 mm: horizontal FOV 63°, vertical FOV 55°
Lens Mount: M12
Focal Length: 2.8 mm and 4 mm, optional
Image Enhancement: 3D DNR
Image Setting: Brightness and sharpness are adjustable by client software or web browser
Day/Night Switch: Auto, scheduled, day, and night
Max. Resolution: 640 × 960
Main Stream: Max. Frame Rate50Hz: 25fps (640 × 480) 60Hz: 24fps (640 × 480)
Sub-Stream: Max. Frame Rate50Hz: 25fps (640 × 960) 60Hz: 24fps (640 × 960)
Network
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API: ISAPI, RS-485, HTTP
Simultaneous Live View: Up to 6 channels
User/Host: Up to 32 users 3 levels: Administrator, Operator and User
Client: iVMS-4200
Web Browser: IE8+, Chrome31-44, Firefox 30.0 – 51
Alarm Trigger: Video tampering, alarm input, alarm output, network disconnected, IP address conflict, illegal login
General Function: Anti-flicker, heartbeat, password protection, watermark, email data report
Interface
Communication Interface: 1 RJ45 10M/100M Ethernet port 1 RS-485 interface
Alarm: 2 inputs, 1 output (up to 24 VDC 1 A, or 110 VAC 500 mA)
General
Power Supply: 12 VDC ± 25%, terminal block PoE (802.3af, class 3)
Power Consumption And Current: 12 VDC, max. 7 W, 0.6A PoE(802.3af, 36 V to 57 V), max. 7 W, 0.2 A to 0.13 A
Material: Body: metal; enclosure: plastic
Dimensions: Camera: 226 × 88 × 64 mm (8.88″ × 3.48″ × 2.50″) Package: 260 × 125 × 125 mm (10.24″ × 4.92″ × 4.92″)
Weight: Approx.850 g (1.87 lb.), 1050 g (2.31 lb.) with package
Operating Conditions: –30°C to +60°C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Protection Level: IP66
Compression Standard
H.264 Compression Type: Baseline Profile/Main Profile/High Profile
Video Compression: Main stream: H.264 Sub-stream: H.264
Video Bitrate: 32 Kbps to 8 Mbps
IR
IR Range: Up to 5 m
