Camera
Image Sensor: 1/2.7″ Progressive Scan CMOS
Min. Illumination: Without /M model:,Color: 0.025 Lux @ (F1.2, AGC ON), Color: 0.109 Lux @ (F2.5, AGC ON),B/W: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.022 Lux @ (F2.5, AGC ON),With /M model:,Color: 0.025 Lux @ (F1.2, AGC ON), Color: 0.069 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.014 Lux @ (F2.0, AGC ON)
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
Day &Night: Electronic
Wide Dynamic Range: 120dB
DNR: 3D DNR
Lens
Lens: Without /M model: 3.7 mm,With /M model: 2.8 mm, 4 mm
Auto-Iris: No
Focus: Fixed
FOV: Without /M model: 3.7 mm,horizontal FOV: 51°, vertical FOV: 38°, diagonal FOV: 64°,With /M model:,2.8 mm,horizontal FOV: 74°, vertical FOV: 55°, diagonal FOV: 93°,4 mm,horizontal FOV: 55°, vertical FOV: 41°, diagonal FOV: 70°
Lens Mount: M12
Video
Max. Resolution: 1280 × 960
Main Stream: 50Hz: 25fps (1280 × 960, 1280 × 720),60Hz: 30fps (1280 × 960, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Third Stream: 50Hz: 1fps (1280 × 960, 1280 × 720, 704 × 576, 640 × 480),60Hz: 1fps (1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Video Compression: H.265/H.264/MJPEG
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 8 Mbps
Smart Feature-Set
Behavior Analysis: Line crossing detection, intrusion detection, region entrance detection, region exit detection, unattended baggage detection, object removal detection
Region Of Interest: Support 1 fixed region for main stream, sub-stream and third stream
Exception: Scene change detection, defocus detection
Face Detection: Yes
Image Enhancement: 3D DNR
Image Setting: Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night Switch: Day/Night/Auto/Schedule
Network
Network Storage: Support NAS (NFS, SMB/CIFS)
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
API: ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View: Up to 6 channels
User/Host: Up to 32 users,3 levels: Administrator, Operator and User
Client: iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Alarm Trigger: Motion detection, video tampering, IP address conflict, illegal login
Interface
Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
Audio: 1 input (line in)
General
General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Reset: Yes
Power Supply: 12 VDC ± 20%, Φ 5.5 mm coaxial plug power
Power Consumption And Current: 12 VDC, 0.3 A, max. 3 W
Dimensions: Without /M model: 31 mm × 31 mm × 26 mm (1.2″ × 1.2″ × 1″),With /M model: 31 mm × 31 mm × 39 mm (1.2″ × 1.2″ × 1.5″)
Weight: With package: approx. 202 g (0.4 lb.),Camera: approx. 93 g (0.2 lb.)
Battery
Operating Condition: -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Compression Standard
H.264+: Yes
H.265+: Yes
