Description
Camera
Image Sensor: 1/1.8ʺ Progressive Scan CMOS
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON); B/W: 0.0002 Lux @ (F1.2, AGC ON)
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Yes
WDR: 140 dB
Day & Night: IR cut filter
Lens
Auto-Iris: P-iris
Focus: ABF (auto back focus)-
FOV: 3.8 to 16 mm, F1.4, horizontal FOV 100.7° to 27.3°, vertical FOV 56.2° to 15.4°, diagonal FOV 115.5° to 31.3°;11 to 40 mm, F1.4, horizontal FOV 35.8° to 11.2°, vertical FOV 19.6° to 6.3°, diagonal FOV 41.7° to 12.8°-
Lens Mount: CS mount
Illuminator
IR Range: 3.8-16 mm: up to 80 m;11-40 mm: up to 120 m-
Wavelength: 850 nm-
Video
Max. Resolution: 1920 × 1080
Main Stream: 50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720) ,60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 16 Mbps
H.264+: Main stream support
H.265+: Main stream support
Scalable Video Coding (SVC): H.264 and H.265 encoding
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Smart Feature-Set
Smart Event: Line crossing detection, up to 4 lines configurable ,Intrusion detection, up to 4 regions configurable ,Region entrance detection, up to 4 regions configurable ,Region exiting detection, up to 4 regions configurable ,Unattended baggage detection, up to 4 regions configurable ,Object removal detection, up to 4 regions configurable ,Face detection: detects faces and upload images ,Scene change detection, defocus detection,
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Road Traffic And Vehicle Detection: yes
Region Of Interest: 4 fixed regions for main stream, sub stream, third stream, fourth stream, and fifth stream, and dynamic tracking
Perimeter Protection: Line crossing, intrusion, region entrance, region exiting ,Support alarm triggering by specified target types (human and vehicle) ,Filtering out false alarm caused by target types such as leaf, light, animal, and flag, etc.
Accuracy: Capture rate > 98%;Vehicle moving direction recognition accuracy > 96%;Mistaken capture rate < 2% (entrance/exit), < 5% (checkpoint)-
Blacklist And Whitelist: Max. 10,000 records-
No License Plate Detection: Yes-
Motorcycle LPR: Yes (only applicable to checkpoint)-
Image Enhancement: BLC, HLC, 3D DNR, Defog, EIS
Image Setting: Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping: Yes
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
Network
Network Storage: Support microSD/SDHC/SDXC card (256 GB) local storage and NAS (NFS,SMB/CIFS), ANR
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Security: RTP/RTSP OVER HTTPS, password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels: administrator, operator and user
Client: iVMS-4200, Hik-Connect, iVMS-4500
Web Browser: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface: 1 RJ45 10M/100M/1000M Ethernet port ,1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Audio: 1 input (line in), 1 output, mono sound
Alarm: 2 inputs, 2 outputs (max. 24 VDC/VAC, 1A max.)
On-Board Storage: Built-in microSD/SDHC/SDXC slot, up to 256 GB
Video Out: 1Vp-p composite output (75 Ω/CVBS)
Firmware Version: 5.5.62
General
General Function: One-key reset, anti-flicker, five streams and up to 5 custom streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Power Supply: 24 VAC ± 20%, two-core terminal block
Material: Metal
Dimensions: 465.4 × 160 × 169.2 mm (18.3″ × 4.3″ × 6.7″);With package: 683 × 223 × 265 mm (26.9″ × 8.8″ × 10.4″)
Weight: 3800 g (8.4 lb);With package: 6000 g (13.2 lb)
Power Consumption And Current: 24 VAC, 1.6 A, max. 30 W
Approval
Protection: IP66, IK10
