Description
Camera
Image Sensor: 1/1.8″ Progressive Scan CMOS
Min. Illumination: 0.05 Lux @ (F1.2, AGC ON), 0.25 Lux @ (F2.6, AGC ON), 0 Lux with IR
Shutter Speed: 1/3 s – 1/100,000 s
Slow Shutter: Support
DNR: 3D DNR
WDR: Digital WDR
Day & Night: IR cut filter
Lens: 1.27 mm, F2.6; horizontal field of view: 180° (wall mount), 360°(ceiling mount), 360°(table mount)
Lens Mount: M12
Audio
Audio Compression: Max. 48 kHz
Environment Noise Filtering: Support 15 display modes in total (including display modes of different mount types and decoding modes):,Fisheye View, 180 Panorama View, 4PTZ, Fisheye + 3PTZ, Fisheye + Panorama + 3PTZ, 360 Panorama View, 360 Panorama + PTZ, 360 Panorama + 3PTZ, 360 Panorama + 6PTZ, 360 Panorama + 8PTZ, 2PTZ, Fisheye + 8PTZ, Panorama View, Panorama + 3PTZ, Panorama + 8PTZ
Audio Sampling Rate: support
Audio I/O: support
Image Enhancement: BLC/3D DNR
Day/Night Switch: Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Settings: Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Sub-Stream: 50Hz: 12.5fps (720 × 720, 704 × 576),60Hz: 15fps (720 × 720, 704 × 480)
ROI (Region Of Interest): Support 3 fixed region for each stream
Max. Resolution: 3072 × 2048
Main Stream: 50Hz: 25fps (3072 × 2048, 2048 × 2048, 1280 × 1280),60Hz: 24fps (3072 × 2048), 30fps (2048 × 2048, 1280 × 1280)
Network
Protocols: Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login, HDD full, HDD error
Security: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Detection: Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Firmware Version: One-key reset, anti-flicker, heartbeat, password protection, privacy mask, watermark, IP address filter
Interface
Communication Interface: Built-in microSD/SDHC/SDXC slot, up to 128 GB
Alarm: 1 3.5mm audio interface, Mic in/Line in (with – S model); ,1 built-in microphone by default, -42dB,1 3.5mm audio output interface (with – S model); ,1 built-in speaker by default, support echo cancellation
Video Output: 1 RJ45 10M/100M Ethernet port,With –S model: 1 RS-485 interface
On-Board Storage: With –S model:,1 input, 1 output (up to DC24V 1A or AC110V 500mA)
Housing Interface: Yes
General
Power Supply: Indoor temperature: -10 °C to +50 °C (14 °F – 122 °F),With –V model: Outdoor temperature: -30 °C – 60 °C (-22 °F – 140 °F),Humidity 95% or less (non-condensing)
Weight: 164 × 152.8 × 43.8 mm (6.46” × 6.02” × 1.72”),With –V model: 164 × 152.8 × 49.5 mm (6.46” × 6.02” × 1.95”)
Power Consumption: DC 12 V ± 10%, 0.78A,PoE (802.3af, class 3), 0.33 – 0.21A
Accessory: With – V model: IEC60068-2-75Eh, 20J; EN50102, up to IK10 for camera housing,With – V model: IP66
Shipping Weight: Max. 12W
Compression Standard
H.264+: Support only when the display mode is Fisheye View
H.264 Type: Baseline Profile/Main Profile/High Profile
Video Compression: Main stream: H.264,Sub stream: H.264/MJPEG
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Video Bit Rate: 256 Kbps – 16 Mbps
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
IR
IR Range: 15 m
Live View Display
Display Mode: Support table, wall, and ceiling
People Counting
People Counting: ONVIF (PROFILE S, PROFILE G), ISAPI
Road Traffic And Vehicle Detection
Accuracy: 1400 g (3.09 lbs)
Smart Feature-Set
Line Crossing Detection: Cross a pre-defined virtual line, up to 4 pre-defined virtual lines supported
Behavior Analysis: Enter and loiter in a pre-defined virtual region, up to 4 pre-defined virtual regions supported
