HIKVISION DS-2CD6984G1/VR-U/NFC
32 MP 360° VR Network Camera
Features
- High quality imaging with 8 MP resolution for each lens.
- 4 lenses cover up to 720° splicing image to present all scenes that covered by the camera.
- Efficient H.265 compression technology.
- Support on-board storage up to 512 GB (SD card slot)
- 1 FC fiber optical interface, SFP module, single mode, 20 km transmission distance
- Water and dust resistant (IP67)
Specifications
| Camera | |
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Max. Resolution | Panorama: 7680 × 3840, Original: 3840 × 2160 |
| Min. Illumination | Color: 0.002 Lux @ (F1.2, AGC ON) |
| Shutter Time | 1 s to 1/100,000 s |
| Image | |
| Image Settings | saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser |
| Wide Dynamic Range (WDR) | Digital WDR |
| Image Enhancement | BLC,HLC |
| General | |
| Power | 12 VDC ± 25%, 1.2 A, max. 14.4 W, 24 VAC ± 25%, 0.95 A, max. 14 W,three-core terminal block |
| Material | Metal and plastic |
| Dimension | 189 mm × 90.3 mm × 90.3 mm (7.4″ × 3.6″ × 3.6″) |
| Package Dimension | 349 mm × 159 mm × 153 mm (13.74″ × 6.26″ × 6.02″) |
| Weight | Approx. 1170 g (2.58 lb.) |
| With Package Weight | Approx. 1360 g (3 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General Function | Heartbeat,mirror,flash log,password reset via email,pixel counter,one-key reset,password protection,anti-banding |
