Camera
Image Sensor: 1/1.8ʺ Progressive Scan CMOS
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON), 0.004 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Yes
Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
WDR: 140 dB
Day & Night: IR Cut Filter. IR cut filter. Blue glass module to reduce ghost phenomenon.
Lens
Aperture: 2.8 to 12 mm: F1.2 to 2.5 ,8 to 32 mm: F1.6, Constant F1.6 throughout the zoom range
Focus: Auto, semi-auto, manual
FOV: 2.8 to 12 mm, horizontal FOV 103.3° to 38.6°, vertical FOV 54.2° to 21.9°, diagonal FOV 124.2° to 44.3° 8 to 32 mm, horizontal FOV 42.5° to 13.4°, vertical FOV 23.4° to 7.7°, diagonal FOV 49° to 15.3°
Lens Mount: Integrated
Lens Type: Motorized lens, 2.8 to 12 mm and 8 to 32 mm optional
Illuminator
IR Range: Up to 30 m
Wavelength: 850 nm
Video
Max. Resolution1920 × 1080
Video Stream: 5 defined streams and up to 5 custom stream
Main Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) ,60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 16 Mbps
H.264+: Main stream support
H.265+: Main stream support
Scalable Video Coding (SVC): H.264 and H.265 encoding
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Smart Feature-Set
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Region Of Interest: Main stream/sub stream/third stream/fourth stream/fifth stream: 4 fixed regions for each stream
Statistics: Counting
Linkage Method: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
Queue Management: Detects queuing-up people number, and waiting time of each person,Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue ,Supports raw data export for further analysis
Image Enhancement: BLC, HLC, 3D DNR, Defog, EIS, distortion correction
Image Setting: Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping: Yes
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Network
Network Storage: microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR ,Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Smooth Streaming: Yes
Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels, administrator, operator and user
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser: Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Interface
Communication Interface: 1 RJ45 10M/100M/1000M Ethernet port,1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Audio: 1-ch 3.5 mm input (line in), 1-ch 3.5 mm output (line out), mono sound
Alarm: 1 input, 1 output (max. 24 VDC/VAC, 1A)
Power Output: 12 VDC, max. 200mA
Interface Style: Socket style interface
On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Video Out: 1Vp-p composite output (75 Ω/CVBS), only for adjustment
Firmware Version: 5.5.90
Web Client Language: 32 languages ,English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General
General Function: Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Reset: Reset via reset button on camera body, web browser and client software
Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Power Supply: 12 VDC is recommended, 10 to 48 VDC; reverse polarity protection; two-core terminal block; PoE (802.3af, class 3)
Material: Metal
Dimensions: Camera: Φ140.5 × 122.6 mm (Φ5.5″ × 4.8″) ,With package: 244 × 174 × 173 mm (9.6″ × 6.9″ × 6.8″)
Weight: Camera: approx. 950 g (2.09 lb.) ,With Package: approx. 1300 g (2.87 lb.)
Power Consumption And Current: With extra load: 12 VDC, 0.8 A, max. 10.5 W; PoE (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, class 3 ,Without extra load: 12 VDC, 0.6 A, max. 8.0 W; PoE (802.3af, 36 V to 57 V), 0.2 A to 0.3 A, class 3 ,”with extra load” means that an extra device is connected to and powered by the camera.
Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Approval
EMC: 47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
Safety: UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry: 2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
Protection: Ingress protection: IK10 (IEC 62262:2002)
