Camera
Image Sensor: 1/2.5″ Progressive Scan CMOS
Min. Illumination: Color: 0.056 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed: 1s to 1/100,000 s
Slow Shutter: Yes
P/N: Yes
Wide Dynamic Range: 120dB
Day & Night: ICR Cut
Linkage Method: Upload to FTP/NAS/memory card, send email，notify surveillance center
Angle Adjustment: P: -90 to 90°; T: 0 to 60° (2.8mm), 0 to 70° (4/6mm); R: 0 to 355°
Power-Off Memory: No
Lens
Lens Type & FOV: 2.8mm @ F2.0, horizontal FOV 103°, vertical FOV 53°, diagonal FOV 124° 4 mm @ F2.0, horizontal FOV 79°, vertical FOV 41°, diagonal FOV 94° 6 mm @ F2.0, horizontal FOV 50°, vertical FOV 27°, diagonal FOV 58°
Aperture: F2.0
Lens Mount: M12
Illuminator
IR Range: Up to 10m
Wavelength: 850nm
Smart Supplement Light: Yes
Video
Max. Resolution: 3840 × 2160
Main Stream: 50Hz: 25fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 24fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream: 50Hz: 25fps (640 × 480, 704 × 576) 60Hz: 24fps (640 × 480, 704 × 480)
Video Compression: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 16 Mbps
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
H.264+: No
H.265+: No
Bit Rate Control: VBR/CBR
Stream Type: Main stream/Sub-stream
Scalable Video Coding (SVC): H.265 and H.264 support
Region Of Interest (ROI): 4 fixed regions for each stream
Audio
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz/16 kHz/32kHz/44.1kHz/48kHz
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2)
Audio Type: Stereo
Network
Simultaneous Live View: Up to 20 channels
API: ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host: Up to 32 users3 levels: Administrator, Operator and User
Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2
Network Storage: NAS(NFS,SMB/ CIFS)
Client: iVMS-4200, Hik-Connect
Web Browser: Plug-in required live view: IE8+Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+Local service: Chrome 41.0+, Firefox 30.0+
Smart IR: The IR LEDs on camera should support Smart IR function to automatically adjust power to avoid image overexposure.
Day/Night Switch: Day, Night, Auto, Schedule, Triggered by Alarm In (-S)
DNR: 3D DNR
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Enhancement: BLC;HLC;Defog;EIS;3D DNR
Image Parameters Switch: Yes
Image Settings: Saturation;brightness;contrast;sharpness;white balance
Privacy Mask: Yes
Interface
Alarm: -S: 1 input, 1 output (max. 36 VDC, 30mA)
Audio: Without -S：2 built-in mics -S: 2 built-in mics, 1 line in，1 line out
RS-485: -S: 1 RS-485 interface, half duplex
On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Hardware Reset: Yes
Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
Heater: Yes
Smart Feature-Set
Smart Event: No
Intelligent (Traditional Algorithm)
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
General
Online Upgrade: Yes
Firmware Version: V5.5.94
Web Client Language: 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General Function: mirror;password protection;watermark;IP address filter;one-key reset;anti-flicker;heart
Software Reset: Yes
Startup And Operating Conditions: -40° to 60°, humidity 95% or less (non-condensing)
Power Supply: 12 VDC, POE (802.3af)
Power Consumption And Current: 12VDC, 0.9A, max. 11 W POE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 11 W
Power Interface: Φ5.5 mm coaxial power plug
Material: Metal
Camera Dimension: 164.3 × 84.6 × 67.4 mm (6.5″ × 3.3″ × 2.7″)
Package Dimension: 227 × 172 × 125 mm (8.9″ × 6.8″ × 4.9″)
Camera Weight: 770g (1.7 lb.)
With Package Weight: 1053g (2.3 lb.)
Approval
Class: Class B
Protection: Ingress protection: IP67, IK10
EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
