Camera
Image Sensor: 1/1.8ʺ Progressive Scan CMOS
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Yes
Angle Adjustment: Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°
WDR: 140 dB
Day & Night: IR cut filter
Lens
Auto-Iris: P-iris
Aperture: F1.2 to 2.5
Focus: Auto, semi auto, manual
FOV: Horizontal FOV 109.2° to 38.9°, vertical FOV 56.2° to 21.9°, diagonal FOV 134.5° to 45°
Lens Mount: Integrated
Lens Type: Motorized lens, 2.8 to 12 mm
Illuminator
IR Range: 50 m
Wave: length850 nm
Video
Max. Resolution: 2560 × 1440
Video Stream: 5 defined streams and up to 5 custom stream
Main Stream: 50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720) ,60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream: 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
Video Bit Rate: 32 Kbps to 16 Mbps
H.264+: Main stream support
H.265+: Main stream support
Scalable Video Coding (SVC): H.264 and H.265 encoding
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/ 8-320Kbps(MP3)
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Smart Feature-Set
Smart Event: Line crossing detection, up to 4 lines configurable ,Intrusion detection, up to 4 regions configurable ,Region entrance detection, up to 4 regions configurable ,Region exiting detection, up to 4 regions configurable ,Unattended baggage detection, up to 4 regions configurable ,Object removal detection, up to 4 regions configurable ,Face detection: detects faces and upload images ,Scene change detection, defocus detection,
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Face Capture: Face detection performance: detects up to 30 faces at the same time;Detectable face position: supports swing left and right from -90° to 90°,tilt up and down from -30° to 60°
Road Traffic And Vehicle Detection: –
Region Of Interest: -aMain stream/sub stream/third stream/fourth stream/fifth stream: 4 fixed regions and dynamic face tracking for each stream
Statistics: Counting
Perimeter Protection: Line crossing, intrusion, region entrance, region exiting ,Support alarm triggering by specified target types (human and vehicle) ,Filtering out false alarm caused by target types such as leaf, light, animal, and flag, etc.
Linkage Method: Trigger recording：memory card, network storage, pre-record and post-record ;Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email ;Trigger notification: HTTP, ISAPI, alarm output (-S), Email
Accuracy: –
Blacklist And Whitelist: –
No License Plate Detection: –
Motorcycle LPR: –
Queue Management: Detects queuing-up people number, and waiting time of each person ;Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue ;Supports raw data export for further analysis
Image Enhancement: BLC, HLC, 3D DNR, Defog, EIS, distortion correction
Image Setting: Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping: Yes
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Network
Network Storage: microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR ,Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Smooth Streaming: Yes
Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels: administrator, operator and user
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser: Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Interface
Communication Interface: 1 RJ45 10M/100M/1000M Ethernet port
Audio: 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
Alarm: 2 inputs, 2 outputs (max. 24 VDC/VAC, 1A)
Power Output: 12 VDC, max. 200mA
Interface Style: Tail cables
On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Video Out: 1Vp-p composite output (75 Ω/CVBS), only for adjustment
Firmware Version: 5.6.0
Web Client Language: 32 languages ,English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General
General Function: Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Reset: Reset via reset button on camera body, web browser and client software
Startup And Operating Conditions: -30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F) Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 20%, two-core terminal block; reverse polarity protection, PoE (802.3at, class 4)
Material: Metal
Dimensions: Camera: Φ140 × 351 mm (Φ5.5″ × 13.8″) ;With package: 405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
Weight: Camera: approx. 1.85 kg (4.1 lb.) ;With package: approx. 2.95 kg (6.5 lb.)
Power Consumption And Current: With extra load: 12 VDC, 1.38 A, max. 16.5 W; PoE (802.3at, 42.5 V to 57 V), 0.44 A to 0.32 A, max. 18.5 W; Without extra load: 12 VDC, 1.17 A, max. 14 W; PoE (802.3at, 42.5 V to 57 V), 0.38 A to 0.28 A, max. 16 W ;”With extra load” means that an extra device is connected to and powered by the camera.
Heater: -H: yes
Storage Conditions: -30 °C to 65 °C (-22 °F to 149 °F) ,Humidity 95% or less (non-condensing)
Approval
EMC: 47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
Safety: UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry: 2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
Protection: Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
