描述
AR-101-PBI-L
Hybrid Switch (IR & Push Button)
AR-101-PBI-L 屬Soyal 碩陽門禁產品。傑成系統有限公司（香港防盜）為Soyal 碩陽產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合電鎖、出門掣及管理軟件一併施工。方案可參考門禁系統。規格以原廠資料為準。
功能重點
- Tempered-glass stainless-steel panel — scratch-resistant, wear-resistant, and resistant to aging.
- Suitable for installation as both door exit button.
- The sensing distance can be adjusted from 1cm to 8cm.
規格
AR-101-PBI-L Specifications
| Active distance | 1-8cm(With Additional Physical Button) | |
| Voltage | DC 12~24V | |
| Current | DC 12V Standby: 30mA / Max. during activation: 75mA | |
| Contact capacity | 30VDC 1A / 125VAC 0.3A | |
| Output Contact | 1 Form C (1A / VAC/VDC 30V) | |
| Dimmension (mm) | Touch-less Infrared Sensor Push Button (Anti-Interference) AR-101-PBI-L |
39(H)X39(W)X15(D) |
| Stainless Steel Panel (Slim Type) |
108(H)X41(W)X2(D) | |
| Stainless Steel Panel (US Type) |
122(H)X72(W)X2(D) | |
| Stainless Steel Panel (Square EU Type) |
86(H)X86(W)X2(D) | |
| Environment | Operating Temperature | -20℃ ~ +70℃ |
| Storage Temperature | -40℃ to +75℃ | |
| Operating Humidity | 0%~90% (non-condensing) | |
| Storage Humidity | 0%~95% (non-condensing) | |
| Material | Stainless Steel (Fire-proof level: 94V0) | |
| Panel Material | Glass | |
| Ingress Protection | NO | |
| Others | Physical Contact （How to use when power off）: Allow access under no power supply situation by pressing any points on the button. |
