描述
Soyal AR-837-P DESFire Card Encoder (Standalone Offline Type) 是Soyal門禁卡機／獨立機。香港防盜為安裝商及經銷商，負責牆面開孔、走線、對接電鎖／出門掣。卡種及讀距以原廠規格為準。
相關方案：Soyal 門禁安裝、門禁系統、辦公室方案。選型可先參閱以上方案頁；原廠規格見下方。
AR-837-P
DESFire Card Encoder (Standalone Offline Type)。
| Frequency | 13.56MHz | |
| Reading Range | 1-3 cm | |
| Read / Write | Read / Write | |
| Standard | ISO14443A (3DES) | |
| Supported Tag | DESFire Tag (EV1, EV2) | |
| Communication Interface | RS485(9600, N, 8, 1) | |
| Watchdog function | Yes | |
| Power Consumption | <5W | |
| Power Supply | 12-24VDC | |
| Relay | Yes | |
| LCD Panel | 128*64 (4 line messages, 16 Characters each line) | |
| Indicator | LED | 6 LED |
| Buzzer | 1 | |
| Housing Material | ABS(Fire-proof level: 94V0) | |
| Dimension(mm) | 128(H)X147(W)X60(D) | |
| Net Weight (g) | approx. 470 | |
| Environment | Operating Temperature | -20℃ ~ +70℃ |
| Storage Temperature | -40℃ to +75℃ | |
| Operating Humidity | 0%~90% (non-condensing) | |
| Storage Humidity | 0%~95% (non-condensing) | |
數字以原廠規格書為準。
卡機安裝、調試、保養及維修
香港防盜（持牌主體傑成系統有限公司 KNS SYSTEM LTD）為Soyal門禁卡機的安裝商及經銷商，保安牌照 1507、電業承辦商 029394。工作包括牆面開孔、走線、對接電鎖／出門掣、卡種及權限。高貨值場地不應只用易複製卡。
查詢 2122-9527，WhatsApp 9439-8568。保養見保安系統保養。系統選型見門禁系統。Soyal安裝見Soyal 門禁安裝。
