描述
TOTEN-WA
Network Switching Box
TOTEN-WA 屬TOTEN 圖騰伺服器機櫃及機房設備產品。傑成系統有限公司（香港防盜）為TOTEN 圖騰產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修，可配合網絡佈線、UPS 及機房環境監測一併規劃。方案可參考Server Room 架設及維修。規格以原廠資料為準。
產品說明
Black 21 bit national standard PDU, 10A national standard three flat plug input, 10A universal socket output, with main switch, 3M wire length, installed in the opposite direction
規格
WA Network Switching Box
Features
Compact in size, it takes up little space and is easy to install.
The multiple-folded box opening, the one-piece formed box door flange, and the specially designed seamless foam sealing strip on the door have excellent sealing performance, which can prevent water, mosquitoes and other debris from entering the box, improving the reliability of equipment usage.
The cold-rolled steel plate welded box body is extremely sturdy.
The door of the box can be modified to open left or right according to the user's needs.
The box is pre-installed with a grounding bolt, and there is a grounding nail on the door.
Installation holes are pre-drilled at the rear of the box, so no additional holes need to be drilled.
The main color is the internationally popular RAL7035.
Protection grade
According to EN60529/10.91, it meets the IP66 standard.
It meets the IP66 standard as per EN60529/IEC529 and GB4208-93.
Main materials
SPCC high-quality cold-rolled steel plate is used for manufacturing; thickness: 2.5mm for wall brackets, 2.0mm for supports, and 1.5mm for others.
Surface treatment
Degreasing, pickling, phosphating, electrostatic powder coating.
Ordering code
WA.1045.900
