描述
DS-KIS623-S
IP Video Intercom Kit
DS-KIS623-S 屬海康威視視像對講產品。傑成系統有限公司（香港防盜）為海康威視產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。方案可參考視像對講系統。規格以原廠資料為準。
規格
Door station/System parameters
| Operation system | Linux |
|---|---|
| Processor | Embedded high performance processor |
| Memory | / |
| RAM | 1 GB |
| ROM | 4 GB |
Door station/Video parameters
| Supplement light | IR light, up to 3 m |
|---|---|
| Resolution | Main stream: 4MP(2688x1520P), 2MP(1920x1080P), 1MP(1280x720P) Sub stream: 2MP(1920x1080P), 1MP(1280x720P), 0.3MP(640x480P) |
| Lens | 3 |
| FOV | Center Lens: Horizontal: 180°; Vertical: 105° Side Lenses: Horizontal: 75°; Vertical: 150° |
| Video compression standard | H.264; H.265; MJPEG |
Door station/Audio parameters
| Volume adjustment | Adjustable |
|---|---|
| Audio Performance | 50cm, 85dB |
Door station/Capacity parameters
| User capacity | 10000 |
|---|---|
| Card capacity | 50000 |
Door station/Network parameters
| Network protocol | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, IPv4, IPv6, UDP, WebSocket, WebSockets，ONVIF, SIP v2 (RFC3261) |
|---|---|
| Wi-Fi | 2.4GHz |
| Bluetooth | Supported |
| Wi-Fi Protocol | IEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax |
| Wi-Fi Type | WiFi 6 |
Door station/Authentication parameters
| Card reading frequency | 13.56 MHz |
|---|---|
| Card Type | M1 Card;Desfire |
| Card Reading Distance | 3 cm |
| Authentication mode | Face;Card;Bluetooth;Mobile APP;Indoor Station;PIN Code;QR Code |
Door station/Application
| Mobile APP | Hik-Connect |
|---|---|
| Motion Detection | Support |
| Playback | Support |
| Call Elevator | Support |
| Smart Features | 1. Sound Classification Detection: Scream, Glass Breaking Sound, Crying Sound, Gunshot Recommended Detection Distance: ＜ 3 m 2. Portrait Centered 3. Perimeter Detection: Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection Recommended Detection Distance: ＜ 10 m Supports Person and Vehicle Target Detection 4. Fall Down Detection Recommended Detection Distance: ＜ 5 m 5. Target Microphone Pickup Range: Forward 60° Sector Area Recommended Detection Distance: 0.5 m ~ 1 m 6. Smart Noise Reduction Supports Common Steady-State and Non-Steady-State Street Noises Noise Reduction Level: > 15 dB |
Door station/Device interfaces
| Network interface | 1 RJ-45, 10/100 Mbps self-adaptive |
|---|---|
| Exit button | 2 |
| Lock control | 2 relay, Max. 30 VDC 1 A |
| RS-485 | 1 |
| Door contact input | 2 |
| Alarm input | 4(includeExit button and Door contact input) |
| Alarm output | 0 |
| TAMPER | 1 |
| TF card | Support TF card, up to 128 G |
| Supported TF Format | FAT32;exFAT |
Door station/General
| Button | 13 physical button(s) |
|---|---|
| Indicator | 3 |
| Power consumption | With Lock: < 14 W Without Lock: < 20 W |
| Working temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Working humidity | 10% to 90% (no-condensing) |
| Application environment | Outdoor |
| Dimension (W × H × D) | 202.6 mm × 95.6 mm × 34.1 mm (7.98" × 3.76" × 1.34") |
| Protective level | IP66, IK08 |
| Installation | Surface mounting & Flush mounting(With braket) |
| Material | Rear Shell Material: Plastic Front Shell: Aluminum Alloy & Plastic Frame: Aluminum Alloy Viewing Window Panel Material: Plastic |
| Power supply | 12 VDC, 2 A,IEEE 802.3 at, standard PoE |
| Language | English, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese |
| Power Supply Output | Max. 12 VDC, 500mA |
Indoor station/Audio parameters
| Audio input | 1 built-in omnidirectional microphone |
|---|---|
| Audio output | 1 built-in loudspeaker |
| Audio quality | Noise suppression and echo cancellation |
| Audio compression standard | G.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1 |
| Audio compression bitrate | 16~64Kps |
Indoor station/Network parameters
| Wired network | 1 RJ-45, 10/100 Mbps self-adaptive |
|---|---|
| Wireless network | 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Network protocol | TCP/IP, SIP, RTSP |
Indoor station/Device interfaces
| RS-485 | 1 RS-485 (Half duplex) |
|---|---|
| Alarm input | 8-ch alarm inputs |
| Relay output | 2 |
| TF card | Support TF card, up to 128 G |
Indoor station/General
| Power consumption | ≤ 5 W |
|---|---|
| Power supply | 12 VDC, 1 A,IEEE802.3af, Standard PoE |
| Working temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working humidity | 10% to 90% |
| Dimension (L x W x H) | 178.4 mm × 126.4 mm × 21.8 mm (7.02" × 4.98" × 0.86") |
