描述
BK500I
Back-UPS 500VA, 230V
BK500I 屬APC不斷電系統（UPS）產品。傑成系統有限公司（香港防盜）為APC產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。UPS 可為閉路電視錄影機、門禁控制器、網絡設備及伺服器提供後備電源，方案可參考Server Room 架設及維修。規格以原廠資料為準。
規格
主要規格
| Main input voltage | 230 V |
|---|---|
| Input connection | IEC 60320 C14 |
| Efficiency at full load | 196…280 V |
| Input frequency | 50/60 Hz +/- 5 Hz manual switch |
| Output voltage | 230 V |
| Rated power in W | 300 W |
| Rated power in VA | 500 VA |
| Output connection | 3 IEC 60320 C13; 1 IEC 60320 C13 surge; 2 IEC 60320 |
| Maximum configurable power in VA | 500 VA |
| Maximum configurable power in W | 300 W |
| Transfer time | 4 ms typical : 8 ms maximum |
| UPS topology | Standby |
補充規格
| Control panel | Output power on indicator LED |
|---|---|
| Free slot | 0 |
| Surge energy rating | 300 J |
| Noise filtering | Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Number of rack unit | 0U |
| Number of cables | 1 |
| Color | Beige |
| Height | 15.2 cm |
| Width | 8.6 cm |
| Depth | 33.3 cm |
| Product weight | 7 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| Two post mountable | 0 |
| USB compatible | No |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Range of product | Back-UPS |
| Product or component type | Uninterruptible power supply (UPS) |
使用環境
| Product certification | CE |
|---|---|
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -15…45 °C |
| Storage altitude | 0…15240 m |
| Relative humidity | 0…95 % |
| Storage relative humidity | 0…95 % |
| Heat dissipation | 4 Btu/h |
| Operating altitude | 0…10000 ft |
電池及後備時間
| Battery type | Lead-acid battery |
|---|---|
| Extendable runtime | 0 |
| Included battery module | 0 |
| Empty battery slot | 0 |
| Typical recharge time | 7 h |
| RBC quantity | 1 |
| Battery charging power | 12 W rated |
