SRC3000XLI
Smart-UPS RC 3000VA, 230V, rackmount w/kit, 4U
SRC3000XLI 屬APC不斷電系統（UPS）產品。傑成系統有限公司（香港防盜）為APC產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。UPS 可為閉路電視錄影機、門禁控制器、網絡設備及伺服器提供後備電源，方案可參考Server Room 架設及維修。規格以原廠資料為準。
產品說明
The APC Smart-UPS RC is an online UPS with a power rating of 3000VA and output power capacity of 2100 watts. It operates at a nominal voltage of 230V and includes output connections such as IEC 60320 C13. The UPS features double conversion online technology and sine wave output.
規格
主要規格
| Main input voltage | 230 V AC 1 phase |
|---|---|
| Other input voltage | 220 V |
| Input connection | IEC 60320 C20 |
| Switching current capacity | 20 A |
| Efficiency at full load | 160…280 V |
| Input frequency | 50/60 Hz +/- 5 Hz auto-sensing |
| Output voltage | 230 V 1 phase |
| Other output voltage | 220 V |
| Rated power in W | 2100 W |
| Rated power in VA | 3000 VA |
| Output connection | 8 IEC 60320 |
| Output connection | Hard wire 3-wire (H N + E) for 1 zone(s) |
| Bypass type | Built-in bypass |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 3 % |
| Maximum configurable power in VA | 3000 VA |
| Maximum configurable power in W | 2100 W |
| UPS topology | On-Line |
| Waveform type | Sine wave |
| Efficiency | 89 % (full load) |
| Output frequency | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz sync to mains |
補充規格
| Additional information | Configurable for 220 or 230V nominal output voltage |
|---|---|
| Battery type | Lead-acid internal |
| Emergency power off | Optional |
| Free slot | 1 |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| UPS connectivity | Serial port; USB port |
| Data line protection | RJ45 modem/fax protection (four wire dual line) |
| Surge energy rating | 420 J |
| Noise filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Number of rack unit | 4U |
| Cable length | 2.4 m |
| Color | Black |
| Height | 175 mm |
| Width | 432 mm |
| Depth | 457 mm |
| Product weight | 34 kg |
| Mounting location | Front |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted with kit |
| Two post mountable | 0 |
| USB compatible | No |
| Mounting mode | Rack-mounted with included kit |
| Provided equipment | CD with software; Smart UPS signalling RS-232 cable; User manual |
| Number of power modules | 1400 |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Additional specification | Entry level |
| Redundant | No |
| Range of product | Smart-UPS On-Line |
| Product or component type | Uninterruptible power supply (UPS) |
使用環境
| Standard | EN/IEC 62040-1:2019/A11:2021; EN/IEC 62040-2:2006/AC:2006; EN/IEC 62040-2:2018 |
|---|---|
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -20…50 °C |
| Storage altitude | 0…15240 m |
| Relative humidity | 0…95 % |
| Storage relative humidity | 0…95 % |
| Acoustic level | 45 dBA |
| Heat dissipation | 652 Btu/h |
| Operating altitude | 0…10000 ft |
電池及後備時間
| Battery type | Lead-acid battery |
|---|---|
| Extendable runtime | 1 |
| Included battery module | 1 |
| Empty battery slot | 1 |
| Typical recharge time | 2 h |
| RBC quantity | 1 |
| Battery life | 3…5 year(s) |
| Battery charging power | 344 W rated |
