CBN NV11-0MH Pancake IP Camera

– HD 60 Frame Pancake IP Camera
– 1/3” Progressive scan CMOS Sensor
– Dual-Codec (H.264/MJPEG)
– Progressive scan megapixel (1.3M CMOS)
– Multi profile streaming
(5 different streams per Resolution, Frame, Rate, Codec)
– Digital PTZ, video crop
– Analog video output (CVBS)
– Built-in standard PoE
– Two-way audio communication
– 3-Axis lens mount
– Compact design & Easy installation
– Vandal proof, Weather proof (IP66)

描述

ModelNV11-0MH
..[Camera]
Image SensorProgressive scan 1/3 inch CMOS 1.3M pixels
Full resolution1,280 x 720 pixels (HD)
Sync. SystemInternal
Lens3.6mm, F 1.8
Day & NightAUTO, DAY ,NIGHT
SensitivityDark Hunter Max – 0.0005 Lux
Back Light CompensationON / OFF
White BalanceATW(2.000 K ~ 10,000 K)/ MANUAL / PUSH
ExposureDC/ ESC
WDRON / OFF
3D-DNR0~20
Dark HunterAUTO ON (Max.X128) / OFF
Privacy MaskON / OFF (10 Programmable Zone)
Motion DetectionON / OFF (4 Programmable Zone)
Digital ZoomX1 ~ X12
MirrorH/ V/ Rotate
DEFOGON / OFF
OSD / LanguageBUILT IN Internally ( English…)
..[Video]
Compression methodSimultaneous Dual Codec (H.264 / MJPEG)
Resolution1,280 x 720@60fps
Multi-Profile Streaming* 5 simultaneous video profiles
* Select the codec type, resolution and frame rates for each profile.
Intelligent Bit-rate ControlHybrid Bit Rate control (VBR+CBR)
PTZDigital PTZ & Video crop
Image SettingText overlay, Privacy mask, De-interlace filter
Motion detection3 regions
..[Audio]
Mono Upstream32Kbps G.726 ADPCM, 64Kbps 16bit μ-law PCM ~ MIC / Line-in
Mono Downstream64Kbps 16bit μ-law PCM ~ Line-out
..[Network]
Network ProtocolIPv4, TCP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP, RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP, NTP, DNS, DynDNS
Dynamic IPSupported
Security– User ID & Password protection, IP address filtering,
– Digest Authentication, User Access Log
Streaming method-RTSP streaming with proprietary format for control informations
– Standard RTSP streaming
– HTTP streaming
– Onvif Profile-S
..[External Terminals]
LAN10/100BaseT LAN (auto MDIX)
Analog output1 channel D1 CVBS output of the encoding video
Alarm input / outputAlarm I/O (1 Sensor input & 1 Relay output)
Factory ResetSupported
OtherMIC, Line in / Line out / DC 12V in
..[Installation]
Standard PoEIEEE802.3af Supported
..[System Integration]
Intelligent VideoMotion Detection
Alarm TriggersMotion Detection + Sensor Input + Audio Detection
Alarm EventsVideo file upload(FTP), Still image(Email), Relay output
Alarm Buffer (Audio/Video)configurable Pre-alarm (5~15 sec) & Post-alarm (10~60 sec)
..[Client Software]
NVR264ch (free of charge)
Smart App.Android, iOS (free of charge)
..[Operating Environment, Power, Dimensions]
Operating Temperature-10℃ ~ 50℃
Operating Humidity8 ~ 80% RH
PowerDC 12V, 0.6A
DimensionsØ122mm(4.8”) x 55mm(2.1”)
Weight400g (0.88lbs)
CasingAL, PC, IP66
ApprovalsFCC, CE, KCC
Package informationIP camera, CD (User’s guide, Software…)
..[Optional Items]
Local storageMicro SD card
AdapterDC 12V, 1.5A
