CNB NP24-1P10H PTZ Camera

– Full HD 10x Mini PTZ IP Camera
– Multi-Codec (H.265/H.264/MJPEG)
– 1/3” Progressive scan 2Mega CMOS Sensor
– Full resolution 1,920 x 1,080@60fps
– Multi profile streaming (Max.4)
– 10x Optical/12x Digital, Video Crop
– DarkHunter(x32), WDR
– 8 Swings, 4 Patterns, 8 groups
– IEEE802.3at PoE+
– Weather proof (IP66)

描述

Model NP24-1P10H
..[Camera]
Image Sensor 1/3 Inch Progressive scan 2Mega CMOS
Effective Pixels 1944(H) X1092(V)
Scanning System Progressive scan
S/N Ratio More than 50dB(AGC Off)
Lens Optical x10, Digital x12 Zoom 5.1(W)mm~51(T)mm, F1.6(W)~F1.8(T)
Angular of View Diagonal 68˚(W)~ 6.7˚(T)
Min illumination Dark Hunter Max -0.0005 Lux
..[Pan/Tilt]
Panning/Tilting Ratio Pan: 360˚ endless rotation; Tilt: 90˚
Panning/Tilting Speed Manual: 0.1˚ ~ 360˚/sec (Zoom Proportional)
Preset 127 position with Labels
Auto-scan / Pattern / Tour 8 Swings, 4 Patterns, 8 groups
Auto Flip On/Off (Flips the image when the Tilt angle goes over 90˚)
Power-up Action Resume the last action executed (Preset, Auto-scan, Tour)
..[Function]
AGC Support
Flickerless Support (On/Off)
Shutter speed Max 1/10,000
White Balance Auto indoor / Auto Outdoor / Manual
Dark Hunter Off, x2~x32
Backlight Compensation BLC / WDR / ELC
WDR Range 100~120db
DNR 3DNR + 2DNR
Day & Night Auto(ICR)/ Day / Night
PRIVACY 8 Support
Digital Zoom On/Off (max. x12)
Factory reset Support
..[Interface]
LAN RJ-45(10/100BaseT), Auto MDIX
Alarm 1 Sensor input, 1 Relay output
Audio 1 Mic Line input, 1 Line Output
..[Network]
Video Compression Multi-Coded(H.265 / H.264 / MJPEG)
Max Resolution 1920 x 1080@60fps
Multi-Profile Streaming 4 simultaneous video profiles
Intelligent Bit-Rate Control VBR, CBR
Motion detection 3 regions
Audio Communication Two-way Communication
Mono Upstream 32Kbps G.726 ADPCM
64Kbps 16bit μ-law PCM (MIC / Line-in)
Mono Downstream 64Kbps G.71116bit μ-law PCM(Line-out)
IP(Internet Protocol) IPv4
Network Protocol IPv4, TCP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP, RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP, NTP, DNS, DynDNS
Dynamic IP Support
Security -User ID & Password protection
-IP address filtering
-Digest Authentication
User Access Log
Streaming method -RTSP streaming with proprietary formatfor control informations
-Standard RTSP streaming
-HTTP streaming
-Onvif Profile-S
Intelligent Video Motion Detection
Alarm Triggers Intelligent Video + Sensor Input
Alarm Events Video file upload(FTP), Still Image(Email), Relay output
Alarm Buffer(Audio/Video) configurable Pre-alarm (5~15 sec) & Post-alarm (10~60 sec)
Client Software NVR2, Smart App(Android, iOS)
..[General]
Operating Temperature -10℃~ 50℃
Operating Humidity 0 ~ 80% RH
Power DC12V, Max. 1.0A, IEEE802.3at PoE+
Dimensions (Øx H) Ø146 x 140mm(With Sunshield)
Ø167.9 x 144.5mm(With Sunshield)
Material / IP Ratio AL, PC / IP66
Weight Approx. 2kg
