Description

[:en]Camera

• Image Sensor1/2.4″ Progressive Scan CMOS
• Min. IlluminationColor: 0.008 Lux @ (F1.2, AGC ON), 0.011 Lux @ (F1.4, AGC ON)
• Shutter Speed1/3 s to 1/100,000 s
• Slow ShutterYes
• Day &NightIR Cut Filter
• Wide Dynamic Range120dB
• Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
• DNR3D DNR

Lens

• Lens2.8 to 12 mm
• ApertureF1.4
• FocusAuto
• FOVHorizontal field of view: 114° to 34°,Vertical field of view: 71° to 23°,Diagonal field of view: 154° to 41°
• Lens MountΦ14
• Lens TypeMotorized

Illuminator

• IR RangeUp to 50 m
• Wavelength850nm

Video

• Max. Resolution3072 × 2048
• Main Stream50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub Stream

• 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
  Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)

Video Compression

• Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
• H.264 TypeMain Profile/High Profile
• H.265 TypeMain Profile
• Video Bit Rate32 Kbps to 16 Mbps
• SVCSupport H.264 and H.265 encoding

Audio

• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
• Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)
• Environment Noise Filtering: Yes
• Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Smart Feature-Set

• Behavior AnalysisLine crossing detection, intrusion detection, unattended baggage detection, object removal detection
• Region of InterestSupport 1 fixed region for main stream and sub stream


• Image Enhancement : BLC/3D DNR/HLC
• Image Setting : Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
• Day/Night Switch : Day/Night/Auto/Schedule/Triggered by Alarm In

Network

• Network Storage : Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
• API : ONVIF (PROFILE S, PROFILE G), ISAPI
• Simultaneous Live ViewUp to 6 channels
• User/Host : up to 32 users,3 levels: Administrator, Operator an : d User
• Client : iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
• Web Browser : Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view: Chrome 45.0+, Firefox 52.0+
• Alarm Trigger : Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Interface

• Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
• Audio : 1 input (line in, 3.5 mm), 1 output (3.5 mm), mono sound
• Alarm : 1 input, 1 output (max. 12 VDC, 30 mA), terminal block
• Video Output : 1Vp-p composite output (75 Ω) (For adjustment only)
• On-board Storage : Built-in micro SD/SDHC/SDXC slot, up to 128 GB

General

• Firmware Version : V5.5.80
• Reset : Yes
• Startup and Operating Conditions: -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
• Power Supply : 12 VDC ± 25%,PoE (802.3at, class 4)
• Power Consumption and Current : 12 VDC, 1.2A, max. 14.5W,PoE: (802.3at, 42.5V to 57V), 0.5A to 0.3A, max. 18W
• Material : Front cover: metal, back cover: metal
• Dimensions : Camera: Φ144 × 332.7 mm (Φ5.7″× 13.1″)
• Weight : Camera: 1400 g (3.1 lb.),With package: 2500 g (5.5 lb.)
• Interface Protection : IP66

Approval

• Impact Protection : IK10

Compression Standard

• H.264+ : Main stream supports
• H.265+ : Main stream supports

Smart Feature-set

• Face Detection : Yes
• Exception Detection : Scene change detection
