Description
Camera
Image Sensor: 1/1.7″ Progressive Scan CMOS
Min. Illumination: Color: 0.05 Lux @ (F2.2, AGC ON), B/W: 0.01 Lux @ (F2.2, AGC ON), 0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Support
DNR: 3D DNR
WDR: Digital WDR
Day & Night: IR cut filter
Lens
Aperture: F2.2
Focus: No
FOV: Horizontal FOV: 180°, vertical FOV: 180°
Lens Mount: M12
Focal Length: 1.29 mm
Audio
Audio Compression: 8 kHz/16 kHz
Environment Noise Filtering: yes
Audio: I/O2 built-in microphones, 1 built-in speaker, mono sound -S: 1 Audio input (line in, 3.5 mm), 1 audio output (line out, 3.5 mm)
Image Enhancement: BLC, HLC, defog, 3D DNR
Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In (-S)
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Settings: Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software or web browser
Sub-Stream: 50Hz: 20fps (720 × 720, 640 × 480) 60Hz: 20fps (720 × 720, 640 × 480)
Max. Resolution: 4000 × 3000
Main Stream: 50Hz: 20fps (4000 × 3000), 25fps (3000 × 3000, 2560 × 2560) 60Hz: 20fps (4000 × 3000), 30fps (3000 × 3000, 2560 × 2560)
Network
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API: ONVIF (PROFILE S, PROFILE G), ISAPI
Security: Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels, administrator, operator and user
Client: iVMS-4200, iVMS-4500, Hik-Connect, iVMS-5200, Hik-Central
Web Browser: IE8+, Chrome31.0-44, Firefox 30.0-51, Safari8.0+
Detection: Support microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS,SMB/CIFS), ANR
General Function: One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Firmware Version: 5.5.73
Smart Features: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, Audio exception detection, Intersection Analysis, Heat Map, People Counting
Interface
Communication Interface: 1 RJ45 10M/100M/1000M self-adaptive Ethernet port
Alarm: 1-ch alarm input, max. 12 V; 1-ch alarm output, max 24 VDC, 1 A
On-Board Storage: Support microSD/SDHC/SDXC card (256 G)
General
Power Supply: -40 °C to +60 °C (-40 °F to +140 °F), Humidity 95% or less (non-condensing)
Weight: Approx. 1400 g (3.09 lbs)
Power Consumption: 12 VDC, 1 A, max. 12.5 W s PoE (802.3at, 42.5 to 57 V), 0.4 A to 0.3 A, max. 15 W
Wiper: No
Compression Standard
H.264+: Main stream supports
H.265+: Main stream supports
H.264 Type: Baseline Profile/ Main Profile /High Profile
Video Compression: Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG
H.265 Type: Main Profile
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Video Bit Rate: 32 Kbps to 16 Mbps
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
IR
IR Range: Up to 15 m IR range, 3 LEDs. Each LED is independently controlled.
Wavelength: 850nm
Live View Display
Display Mode: 18 display modes in total Software decoding: Ceiling mount: fisheye view, 180 panorama view, 360 panorama view, 360 panorama + PTZ, 360 panorama + 3PTZ, 360 panorama + 6PTZ, 360 panorama + 8PTZ, 2PTZ, 4PTZ, fisheye + 3PTZ, fisheye +8 PTZ, hemisphere, AR hemisphere, cylinder Wall mount: fisheye view, panorama view, panorama + 3PTZ, panorama + 8PTZ, 4PTZ, fisheye + 3PTZ, fisheye +8 PTZ Table mount: fisheye view, 180 panorama view, 360 panorama view, 360 panorama + PTZ, 360 panorama + 3PTZ, 360 panorama + 6PTZ, 360 panorama + 8PTZ, 4PTZ, fisheye + 3PTZ, fisheye +8 PTZ, cylinder Hardware decoding: Ceiling mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion Wall mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion Table mount: fisheye view, 180 panorama view, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion
Smart Feature-Set
Exception Detection: Audio exception detection
Behavior Analysis: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection
Region Of Interest: 4 fixed regions for main stream
