Description
Camera
Image Sensor: 1/1.8’’ Progressive Scan CMOS
Min. Illumination: 0.002 Lux @ (F1.2, AGC ON)
Shutter Speed: 1/25 s – 1/100,000 s
Angle Adjustment: Pan: 0°~360°, tilt: 45°~90°
WDR: Digital WDR
Day & Night: IR Cut Filter
Lens: 5mm ×4, Pan: 180°, Tilt:78.4°
Lens Mount: CS
Image Enhancement: BLC/ 3D DNR/ROI/Defog
Day/Night Switch: Auto/Schedule/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Settings: Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Sub-Stream: Mode 1:,50Hz: 25fps (704× 320) 60Hz: 30fps(704× 320),Mode 2:,50Hz: 25fps(480 × 768, 320× 512),60Hz: 30fps(480 × 768, 320× 512)
Max. Resolution: 4096 × 1800
Main Stream: Mode 1:,50Hz: 25fps(4096 × 1800, 3840× 1680),60Hz: 30fps(4096 × 1800, 3840× 1680),Mode 2：,50Hz: 25fps(2400 × 3840, 1200 × 1920); ,60Hz: 24fps(2400 × 3840), 30fps(1200 × 1920)
Network
Protocols: Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Security: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour
Simultaneous Live View: ONVIF (PROFILE S, PROFILE G), ISAPI
Detection: NAS (Support NFS,SMB/CIFS), ANR
General Function: User Authentication, Watermark, IP address filtering, Anonymous access
Interface
Communication Interface: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Alarm: 1-ch 3.5 mm audio in( Mic in/Line in)/out interface
Video Output: 1 RJ45 10M/100/1000M Ethernet port, 1 RS-485 interface
On-Board Storage: 1 input, 1 output (up to DC24V 1A or AC110V 500mA)
General
Power Supply: -30°C – 60 °C (-22 °F – 140 °F), Humidity 95% or less (non-condensing), -H: -40 °C – 60 °C
Weight: Φ195×159 mm
Power Consumption: 12 V DC ± 10%/PoE (802.3at); (24 V AC/PoE)
Accessory: IK10
Shipping Weight: 22W
Compression Standard
H.264 Type: Baseline Profile/Main Profile/High Profile
Video Compression: H.264/ MJPEG
Audio Compression: G.711/G.722.1/G.726/MP2L2/AAC/PCM
Video Bit Rate: 32 Kbps to 16 Mbps
Audio Bit Rate: 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2) / 16-64Kbps(AAC)
Road Traffic And Vehicle Detection
Accuracy: 2850g
