Wi-Fi Mini Cube

  • Good quality imaging with 1 MP resolution;
  • Efficient H.264 compression technology;
  • Clear imaging even with strong back lighting due to DWDR technology;
  • Up to 128 GB SD card slot for storage;
  • Provides real-time security via two-way audio;
  • Wi-Fi connection and easy installation;
  • Hik-Connect cloud service and app for remote management and viewing of devices;



Image Sensor: 1/4″ Progressive Scan CMOS

Min. Illumination:0.02Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Speed:1/3 s to 1/100,000 s

Slow Shutter:Support

Day &Night:IR cut filter with auto switch

Wide Dynamic Range:Digital WDR




Lens:2.8mm, horizontal field of view 92°

Lens Mount:M12


IR Range:Up to 10 meters


Max. Resolution:1280 × 720

Video Compression:Main stream: H.264 Sub stream: H.264

H.264 Type:Baseline Profile/Main Profile

Video Bit Rate:32 Kbps – 8 Mbps


Audio Compression:G.711/G.722.1/G.726/MP2L2/PCM

Audio Bit Rate:64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)

Audio Sampling Rate:Max. 16 kHz

Environment Noise Filter:Support

Audio Input/Output:Support mono soundtrack

Smart Feature-Set

Basic Event: Motion Detection

Region Of Interest: Support 1 fixed region for each stream


Image Setting: Brightness, saturation, sharpness, contrast are adjustable via client software

Day/Night Switch: Support auto/scheduled

Main Stream Max. Frame Rate: 50Hz: 25fps (1280 × 720) 60Hz: 30fps (1280 × 720)

Sub Stream Max. Frame Rate: 50Hz: 25fps (704 × 576, 352 × 288, 640 × 480, 320 × 240) 60Hz: 30fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)

BLC:Support, zone optional


Wireless Standards: IEEE802.11b, 802.11g, 802.11n

Frequency: 2.4 GHz – 2.4835 GHz

Channel Bandwidth: 20/40MHz Support

Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transfer Rate:11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps

Wireless Range: 50 meters (The performance varies based on actual environment)


Alarm Trigger: Video Tampering Alarm, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login

Network Storage: Support microSD/SDHC/SDXC card, up to 128 GB local storage

Protocols: 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM


Standard: ISAPI


Audio: 1 build-in microphone, 1 build-in speaker

On-Board Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB


General Function: One-key reset, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark

Reset: Yes

Startup And Operating Conditions: -10 °C to 40°C (14 °F to 104 °F), Humidity 95% or less (non-condensing)

Power Supply: DC 5V ± 15 %, micro USB interface

Power Consumption And Current: Max. 0.9 A,Max. 4.5W

Material: Plastic

Dimensions: Φ 64 × 106.9 mm (Φ 2.52” × 4.21”)

Weight: 115 g (0.25 lbs)

Memory Card: DS-2CV2U01(E)FD-IW: no memory card included DS-2CV2U01(E)FD-IW/16G-T: includes a 16 GB memory card DS-2CV2U01(E)FD-IW/32G-T: includes a 32 GB memory card DS-2CV2U01(E)FD-IW/64G-T: includes a 64 GB memory card
